DC Current (Auto-ranging)
Range Resolution
400.0 µA 0.1 µA
4000 µA 1 µA
40.00 mA 10 µA
300.0 mA 100 µA
10 A 10 mA
Overload Protection: 0.5 A/1000 V and 10 A/1000 V fuse.
Maximum Input: 4000 µA DC on µA range
400 mA DC on mA range
10 A DC on 10 A range
AC Current (Auto-ranging)
Range Resolution
400.0 µA 0.1 µA
4000 µA 1 µA
40.00 mA 10 µA
300.0 mA 100 µA
10 A 10 mA
Overload Protection: 0.5 A/1000 V and 10 A/1000 V fuse.
AC Response: 50 Hz to 400 Hz
Accuracy
±1.0% of rdg ±3 digits
±2.5% of rdg ±3 digits
Accuracy
±1.5% of rdg ±5 digits
±3.0% of rdg ±5 digits
Maximum Input: 4000 µA AC rms on µA
400 mA AC rms on mA
10 A AC rms on 10 A range.
Resistance [Ω] (Auto-ranging)
Range Resolution
400.0 Ω 0.1 Ω
4.000 kΩ 1 Ω
40.00 kΩ 10 Ω
400.0 kΩ 100 Ω
4.000 MΩ 1 kΩ
40.00 MΩ 10 kΩ
Input Protection: 1000 V DC or 1000 V AC rms.
AVO300: Diode Test
Test current
0.3 mA typical/Open <1.5 V
Open circuit voltage: 1.5 V DC typical
Overload protection: 1000 V DC or 1000 V AC rms.
Accuracy
±0.8% of rdg ±5 digits
±0.8% of rdg ±2 digits
±3% of rdg ±8 digits
Resolution Accuracy
1 mV ±10% of rdg ±5 digits
