USE

The hood can be switched on pushing directly onto the requested speed without firstly having
to select 0/1 button.
KEY LED
L 0/1 Light
T1 0/1 Motor
T2 Speed
T3 Speed
T4 Speed
S1 Led
EN
Control Panel
FUNCTIONS
Turns lighting on and off.
on First speed.
When pressed for about 2 seconds the motor is switched off.
Flashing 24h Changeover
This is enabled by pressing and holding the button for
approximately 5". It allows a suction level of 100 m3/h
with a noise level of just 28dB(A). Can be enabled at
any speed, even with the hood turned off. To disable,
press and hold the button for approximately 5".
on Second speed.
Flashing Delay (30')
Press the button for approximately 2" to enable auto-
matic shutdown with a 30' delay. Suitable to complete
elimination of any residual smells. Can be enabled at
any speed and is disabled by pressing the button
briefly.
on Third speed.
Fixed Max. speed
Flashing Intensive speed.
Suitable for the strongest cooking vapours and odours.
The function becomes active when the button is pushed
for about 2 seconds. After 10 minutes of functioning it
turns off automatically. This function can be inter-
rupted by means of pressing any of the buttons.
Fixed Indicates that the Metal grease filters saturation alarm
has been triggered, and the filters need to be washed.
The alarm is triggered after 100 working hours. (Reset;
check the Maintenance-paragraph)
Flashing indicates that the activated charcoal odour filter satura-
tion alarm has been triggered, and the filter has to be
replaced; the metal grease filters must also be washed.
The activated charcoal odour filter is triggered after
200 working hours. (Activation and Reset; check the
Maintenance-paragraph)
