UK
UNI-EX
Handheld Rechargeable Work Light
Important Reminders
• Please read this instruction before any use, maintenance and service of explosion-proof lights.
• The explosion-proof light must be used by a certain professional training person.
• Must use the replacement parts which produced or appointed by the manufacturer for
maintenance. Make sure the maintenance and service are not in a dangerous place and fulfilled by professional
trained person. Using the parts which not manufactured by Scangrip A/S will destroy the explosion-proof
performance of the explosion-proof lights.
• The explosion-proof lights should comply with the relevant laws and regulations of the European Union.
WARNING!
• Do not open when an explosive atmosphere is present!
• Do not charge the battery in hazardous location!
• Do not replace battery when anexplosive atmosphere is present!
WARNING!
Battery Pack:
• Only use the battery pack from Scangrip A/S. Part No.30125800
Battery No.: ZJ18650 3.6V 6700mAh 24.12Wh(Single cell battery capacity:3.6V 3350 mAh).
• Only use the adaptor from Scangrip A/S. Part No.10907620A
Model No.: SA69 Input Voltage: AC100~240V/50-60Hz
Output Current: DC2A Output Voltage: DC5V
• Using other sources parts may lower the intrinsic safety level of the explosion-proof lights. Make sure
charging in non-dangerous environment.
1. STANDARD
IEC 60079-0:2017 Explosive atmospheres 一 Par0:Equipment 一 General requirements
IEC 60079-11:2012 Explosive atmospheres 一 Par11:Equipment protection by intrinsic safety "i"
IEC 60529:2001 Degrees of protection provided by enclosure (IP code)
2. Product Model Definition and Basic Parameters
Product Model Definition
Handheld Rechargeable Work Light UNI-EX 03.5617
Basic Parameters: Table 1.
Table 1: Light Design Parameters
Product Description:
Product Model NO./ Item NO:
Dangerous Zone:
Adaptor:
Battery Type and Capacity:
Power Rating:
Explosion-proof Symbol:
Luminous Flux:
Working Time:
CRI (Ra):
CCT:
IPXX:
Operation Temperature(°C):
Storage Temperature(°C):
Product Dimension:
Product Weight:
Product Model NO.
Product Description
Handheld Rechargeable Work Light
UNI-EX 03.5617
Zone 0、Zone 1、 Zone 2/ Zone 20、Zone 21、 Zone 22
DC5V/2A
3.6V/ 6700mAh 24.12Wh (Li-ion)
3.5W
II 1G Ex ia IIC T3 Ga/II 1D Ex ia IIIC T130°C Da
High 350lm
High 7.5h
>80
5500K~6500K
IP65
-20°C~+45°C
-20°C~+45°C
L220*W70*H39 mm
436g
