Assembly instructions

3. Assembling the cabin

ATTENTION!
Note the floor plans on Page 7 and illustrations from Page 11 onwards.

3.1. Assembling the base frame

Place the impregnated base frame on the foundation as shown on the floor plan
and the foundation illustrations (see Page 7).
Make sure that the base frame is assembled at right angles.
Note the power supply!

3.2. Assembling the cabin walls

Always put the wall planks together with the tongue facing upwards.
NEVER hit the tongue directly with a hammer!
Start by laying the half planks of the front and back walls on the base frame and
then put on the side planks.
Connect the block planks to the concrete foundation at the corners
(see 1.3 on page 4).
Continue row by row - up to and including row 7. Note the position of the ventilation
slide in row 2 and the block planks with holes for the electrical installation.

3.3. Mounting the door

Push the door frame into the opening from above (door opens outward).
Install the door fitting.

3.4. Mounting thewindows

Mount the remaining block planks - up to and including row 12.
First fit the edge strips to the window. Slide the window into the opening from above.

3.5. Assembling the walls

Mount the remaining block planks - up to and including row 18.
Note the position of the block planks with the holes for wiring.
Screw the inner door and window panel at a right angle.
p. 8/10
