28 Operation

3.4 Arc Length Adjustment (ArC)

When you press and hold the adjustment pot (5) for 3 seconds, the arc length function will be active.
EN
The factory setting is 0.0. You can change the arc length adjustment in the range of + 7 / -7 by turning the same
pot to the right or left. As it goes towards +7, the wire approaches the nozzle, the arc length increases. As it goes
towards -7, the wire approaches the welding metal and the arc length decreases. After the desired setting is
made, the setting is exited by pressing the same pot.

3.5 MIG Curve

Set Voltage
Set Voltage
Pre-Gas
Post Gas
Burn Back
Arc On Time
Arc Off Time
Wire Diameter
Thickness
Gas Type
Wire Type
Crater
Mode
Trigger
Method
USER MANUAL | MANUEL D'UTILISATION | РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ | KULLANIM KILAVUZU
Crater Open
Voltage 0 - 25 Slow Release
Pre Gas
On
Set Wire
Slow Release
Crater Closed
Off
Wire 0 - 25
Pre-Gas
Crater Open
Voltage 0 - 25 Slow Release
Pre Gas
On
Set Wire
Slow Release
Crater Closed
Off
Wire 0 - 25
Pre-Gas
Pnt Mode
On
Spot
Pre-Gas
Value Range
0,0 - 9,9 sec
0,0 - 9,9 sec
25 - 0 - 25
0,2 - 9,9 sec
0,0 - 9,9 sec
0,6 - 2,4 mm
0,6 - 20,0 mm
CO₂, Ar/5-10 CO₂, Ar/15-25 CO₂, Ar/2.5 CO₂, Ar/10-15 CO₂, Argon
Steel, AlMg, FCW, AlSi, FCW-M, CuSi, CrNi, CuAl
Active / Passive
Synergic / Smart / Classic
Method / 2 / 4
MIG/MAG - MMA -
LIFT TIG
COMPACT SMART SERIES / KOMPAKT SMART SERİSİ
Crater
Crater
Pnt Mode
Off
Factory Setting
0,1 sec
0,1 sec
0 step
0,2 sec
0,0 sec
1,0 mm
1,0 mm
Passive
2
MIG / MAG
Burn Back
Post Gas
Burn Back
Post Gas
Burn Back
Post Gas
Burn Back
Post Gas
Post Gas
2- Position MIG 4- Position MIG
