14.) Attach the SHIELD by squeezing the mounting springs together and inserting
the springs into the spring guides in the FAN.
FAN
spring guide
mounting springs
Installation For New
Construction Framing
NOTE: Even with new construction, you can use the SheetLock
method; however, ReVent
builders would be more familiar with, as outlined in this section.
WARNING: Disconnect all AC Power Breakers or Fuses before attempting
to cut into your ceiling.
1.) Select a set of holding tabs, depending on the thickness of your sheetrock.
/
in (1.3 cm)
1
2
holding tab
/
in (1.6 cm)
5
8
holding tab
2.) Bend the holding tabs you selected outward.
can still be installed using a method home
®
final securing tab
12
ceiling
TRIM RING
spring guide
SHIELD
installation
®
/
in (1.3 cm)
1
2
holding tab
/
in (1.6 cm)
5
8
holding tab
