Panasonic CS-A18CKPG Manuel D'utilisation page 7

I Setting the Fan Speed
• Press 4 to select:
FAN – Low Fan Speed
FAN – Medium Fan Speed
FAN – High Fan Speed
AUTO
FAN – Automatic Fan Speed
The speed of the indoor fan is adjusted
automatically according to the operation.
The indoor fan stops occasionally during
cooling operation.
I Setting the Vertical Airflow Direction
• Press 5 to select:
AUTO
• For COOL/DRY operation.
AUTO
Swing up/down automatically.
• For HEAT operation
AUTO
When the discharge air temperature is
low such as at the start of the heating
operation, the air blows in a horizontal
direction. As the temperature rises, the
hot air blows in a downwards direction.
I Setting the Horizontal Airflow Direction
• Press 6 to select:-
Indoor
Horizontal Unit
Airflow
Direction
Remote
AUTO
Control
• For COOL/DRY operation.
AUTO
Swing left/right automatically.
• For HEAT operation
AUTO
When the discharge air temperature is
low, there is no air swing. When the
temperature rises, the horizontal airflow
louvers swing left/right automatically.
G Use this air conditioner under the following
conditions:
Indoor
DBT: Dry Bulb Temp
WBT: Wet Bulb Temp
DBT
WBT
Maximum Temperature-Cooling 32 23
(Maximum Temperature-Heating) (30) (-)
Minimum Temperature-Cooling 16 11
(Minimum Temperature-Heating) (16)
(-)
G Notes
• If the unit is not going to be used for an extended
period of time, turn off the main power supply. If it is
left at the ON position, approximately 2.5 W of
electricity will be used even if the indoor unit has
been turned off with the remote control.
• If operation is stopped, then restarted immediately,
the unit will resume operation after 3 minutes.
G Operation Details
COOL – Cooling Operation
• To set the room temperature at your preferred cooling
comfort level.
AUTO – Automatic Operation
• Sense indoor temperature to select the optimum
mode.
• Temperature is not displayed on the remote control
during AUTO operation.
DRY – Soft Dry Operation
• A very gentle Cooling Operation, prior to
dehumidification. It does not lower the room
temperature.
• During Soft Dry operation, the indoor fan operates at
Low fan speed.
HEAT – Heating Operation
• Heat is obtained from outdoor air to warm up the
room. When the outdoor ambient air temperature
(Unit in °C)
falls, the heating capacity of the unit might be
Outdoor
reduced.
• Defrosting Operation.
DBT WBT
Depending on the outdoor temperature, the operation
43 26
occasionally stops to melt the frost on the outdoor
(24) (18)
unit.
16 11
(-5) (-6)
