MagnaTherm FT User's Manual
3. Start-Up and Shut-Down Decal. Located inside the front panel.
WARNING: If you do not follow these instructions exactly, a fire or explosion may result
A. This appliance does not have a pilot. It is equipped with an ignition device which automatically
lights the burner. Do not try to light the burner by hand.
B. BEFORE OPERATING, smell all around the appliance area for gas. Be sure to smell next to
the floor because some gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electric switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
C. Use only your hand to turn the gas valve handle. Never use tools. If the valve handle will
not turn by hand, don't try to repair it, call a qualified service technician. Force or
attempted repair may result in a fire or explosion.
D. Do not use this appliance if any part has been under water. Immediately call a qualified
service technician to inspect the appliance and to replace any part of the control system
and any gas control which has been under water.
1. STOP! Read the safety information above on this label.
2. Turn off all electric power to the appliance.
3. Set the thermostat to lowest setting.
This appliance is equipped with an ignition device which automatically
4.
lights the burner. Do not try to light the burner by hand.
5. Open front doors.
6. Turn off manual gas valve. Valve is off when valve handle is at a
right angle to gas pipe.
7. Wait five (5) minutes to clear out any gas. Then smell for gas,
including near the floor. If you do smell gas, STOP! Follow "B" in the
safety information above on this label. If you don't smell gas, go to
next step.
8. Slowly turn manual gas valve to "ON". Valve handle will be parallel to gas pipe.
9. Replace front panel.
10. Set mechanical thermostats to desired settings.
11. Turn on all electric power to the appliance.
12. Set operating thermostat to desired settings using boiler display.
13. If the appliance will not operate, follow the instructions "To Turn Off Gas To Appliance"
and call your service technician or gas supplier.
1.
Turn off all electric power to the appliance if service is to be performed.
2.
Open front doors.
3.
Set the thermostat to lowest setting.
4.
Turn off manual gas valve. Valve is off when valve handle is at a right angle to gas pipe.
Close front doors.
5.
POUR VOTRE SÉCURITÉ, LISEZ AVANT DE METTRE EN MARCHE
AVERTISSEMENT: Quiconque ne respecte pas à la lettre les instructions dans la présente notice
risque un début d' incendie ou une explosion entraînant des dommages, des blessures ou la mort.
A. Cet appareil n'a pas de pilote. Il est équipé d'un dispositif d'allumage automatique qui
allume le brûleur. N'essayez pas d'allumer le brûleur à la main.
FOR YOUR SAFETY READ BEFORE OPERATING
causing property damage, personal injury or loss of life.
OPERATING INSTRUCTIONS
TO TURN OFF GAS TO APPLIANCE
Gas inlet
Manual Gas Valve
Shown in the
"OFF" Position
Continues on next page.
