REDMC70DUAL
Medium-Large Full Motion TV Mount
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
!
CAUTION:
THE MAXIMUM LOADING WEIGHT
IS 70 LBS. USE WITH PRODUCTS HEAVIER THAN
THE MAXIMUM WEIGHT INDICATED MAY RESULT IN
INSTABILITY AND POSSIBLE PERSONAL INJURY.
Max Screen Size: 60"
V1
P 1
Publicité
Manuels Connexes pour REDATOM REDMC70DUAL
Sommaire des Matières pour REDATOM REDMC70DUAL
- Page 1 REDMC70DUAL Medium-Large Full Motion TV Mount INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS CAUTION: THE MAXIMUM LOADING WEIGHT IS 70 LBS. USE WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHT INDICATED MAY RESULT IN INSTABILITY AND POSSIBLE PERSONAL INJURY. Max Screen Size: 60”...
- Page 2 QUESTIONS? NEED HELP? PLEASE CALL info@redatomproducts.com DISCLAIMER – WARNING INFORMATION Disclaimer –. RED ATOM has extended every effort to ensure to accuracy and completeness of this manual. However, RED ATOM does not claim that the information covers all installation and or operational variables. The information contained in this document is subject to change without notice or obligation of any kind. Regarding the information contained herein, RED ATOM makes no representation of warranty, expressed or implied, and assumes no responsibility for accuracy, sufficiency, or completeness of the information contained in this document.
-
Page 3: Tools Needed
TOOLS NEEDED Herramientas Necesarias Outils Requis 7/32” 3/8” 5.5 mm 10 mm SYMBOLS 150lbs Socket Wrench Caution Tighten Pencil Mark Screwdriver Drill Level Heavy! Llave española Precaución Ajustar Marque con lápiz MW150F64 Destornillador Agujerear Nivel Tres Lourd! Clé ouverte Attention Serrer Marque de crayon Tournevis... - Page 4 HARDWARE PRODUCT NUMBERS SQUARE M6 x 30 M8 x 30 M4 x 30 M8 x 15 M6 x 15 M4 x 12 WASHER M8 x 45 WALL LAG BOLT LAG BOLT STEEL 10mm PHILLIPS ANCHOR ALLEN 8mm x 65mm WASHER STEEL WASHER SPACER SPACER...
- Page 5 STEP 1- REMOVE MONITOR PLATE FROM MOUNT Remove and save Phillips head screws and washers. Screws and washers will be used to reattach monitor plate in step 6. STEP 2A- MONITOR PLATE ATTACHMENT Connect monitor plate to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur...
- Page 6 STEP 2B- MONITOR ADAPTERS ATTACHMENT TO MONITOR PLATE Connect monitor plate with adapters to TV (if necessary) Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Note: See page 3 for other monitor plate configurations. STEP 2C- CURVED BACK TV (MONITOR PLATE) Connect monitor plate to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur...
- Page 7 STEP 2- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT ARE TOO LONG Diagrams show three possible options for using additional washers if hardware screw are too long to properly tighten into back of TV. B or C B or C B or C Select the proper spacer(s) as below if necessary...
- Page 8 STEP 4A- WOOD STUD INSTALLATION (CONCRETE INSTALLATION SKIP TO 3B) Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro. Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre. LEVEL WALL PLATE DRILL BIT WITH INCLUDED...
- Page 9 STEP 4B – SOLID CONCRETE INSTALLATION Solid Concrete Drill Bit Level Drill pilot hole Concreto sólido S. broca Nivelado Realice el agujero piloto Béton massif Foret Level Percez le trou de guidage DRILL BIT LEVEL WALL PLATE NOT INCLUDED WITH INCLUDED BUBBLE LEVEL AND MARK HOLES FOR DRILL BIT PILOT HOLE...
- Page 10 STEP 5 - ATTACH ARM ASSEMBLY TO WALL BRACKET Position Arm Assembly to desired lateral position on wall bracket for opti- mum placement of TV. Secure Arm Assembly to Wall plate using screws removed from Step 3. IMPORTANT! Ensure that the top of the arm assembly tucks INSIDE the top of the wall plate.
- Page 11 STEP 7- ADJUST TILT TENSION/ POST INSTALLATION LEVEL Locking mechanism Mecanismo de fijación Mécanisme de verrouillage a) Rotate handle clockwise Secure Monitor Plate to Arm TV can be leveled (+/-3 as far as possible. using 2 Phillips head screws degrees) as needed. If secu- b) Pull handle to side lateral- removed in step 1.
-
Page 12: Warranty Information
Congratulations! Installation complete WARRANTY INFORMATION This warranty applies to US Residents who purchase from an authorized RED ATOM Dealer. RED ATOM products are covered against defects in materials and workmanship for 5 years. RED ATOM will repair or replace the defective component or product, at its sole discretion. Failure to follow product care instructions from RED ATOM will result in void of warranty.
