Large & Extra Large Tilt Flat Panel Mount
REDLTHD120P
REDXLTHD175P
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
!
CAUTION:
CAUTION: DO NOT EXCEED MAXIMUM
THE MAXIMUM LOADING WEIGHT IS 120
LBS FOR LARGE MOUNT AND 175LBS FOR EXTRA LARGE
LISTED WEIGHT CAPACITY. SERIOUS
INJURY OR PROPERTY DAMAGE MAY
MOUNT. USE WITH PRODUCTS HEAVIER THAN THE
MAXIMUM WEIGHT INDICATED MAY RESULT IN
OCCUR!
INSTABILITY AND POSSIBLE PERSONAL INJURY.
Large Full Motion Mount
Max Screen Size: 60"(L) / 90"(XL)
Max Screen Size: 70"
Max weight: 125lbs
V4
V6
P 1
Publicité
Manuels Connexes pour REDATOM REDLTHD120P
Sommaire des Matières pour REDATOM REDLTHD120P
- Page 1 Large & Extra Large Tilt Flat Panel Mount REDLTHD120P REDXLTHD175P INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS CAUTION: CAUTION: DO NOT EXCEED MAXIMUM THE MAXIMUM LOADING WEIGHT IS 120 LBS FOR LARGE MOUNT AND 175LBS FOR EXTRA LARGE LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY MOUNT.
- Page 2 QUESTIONS? NEED HELP? PLEASE CALL info@redatomproducts.com DISCLAIMER – WARNING INFORMATION Disclaimer –. RED ATOM has extended every effort to ensure to accuracy and completeness of this manual. However, RED ATOM does not claim that the information covers all installation and or operational variables. The information contained in this document is subject to change without notice or obligation of any kind. Regarding the information contained herein, RED ATOM makes no representation of warranty, expressed or implied, and assumes no responsibility for accuracy, sufficiency, or completeness of the information contained in this document.
- Page 3 HARDWARE PRODUCT NUMBERS M4 x 30 M6 x 30 M8 x 30 M4 x 12 M6 x 15 M8 x 15 M8 x 50 LAG BOLT WALL SQUARE LAG BOLT 10mm STEEL 8mm x 65mm ANCHOR WASHER SPACER STEEL WASHER SPACER WASHER PRODUCT COMPONENT PARTS...
- Page 4 STEP 1A - FLAT BACK FLAT PANEL (UNIVERSAL VERTICAL RAILS) Connect Universal Vertical Rails to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur STEP 1B - CURVED BACK FLAT PANEL (UNIVERSAL VERTICAL RAILS) Connect Universal Vertical Rails to flat panel Spacers can also be used to Conecte el adaptador al monitor provide clearance for cables...
- Page 5 STEP 1- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT ARE TOO LONG Diagrams show three options for using additional washers if hardware screws are too long to properly tighten into back of flat panel television. select the proper spacers or spacer suit as below if necessary...
- Page 6 STEP 2 - WOOD STUD INSTALLATION (CONCRETE INSTALLATION SKIP TO STEP 3) STEP 2- CENTER UNIVERSAL MONITOR PLATE Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro. Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre. LEVEL WALL PLATE WITH INCLUDED BUBBLE LEVEL AND...
- Page 7 STEP 2C - MOUNT WALL PLATE TO WALL Mount wall plate 16” STUD (Large Tilt Mount) Coloque la placa de pared 16” or 24” STUD (Extra Large Tilt Mount) Montez la plaque murale...
- Page 8 STEP 3 – SOLID CONCRETE INSTALLATION Use wall plate to mark mounting locations/drill pilot holes Use la placa de pared para marcar el lugar donde se realizará la instalación Utilisez la plaque murale pour marquer l'emplacement de montage Level Solid Concrete Drill Bit Drill Pilot Hole DRILL BIT...
- Page 9 STEP 3C - SOLID CONCRETE INSTALLATION. Mount wall plate Coloque la placa de pared Montez la plaque murale Insert wall anchors gently into concrete wall with hammer if necessary Concrete Wall Concrete Wall Hammer...
- Page 10 STEP 4A - ATTACH PANELTO WALL PLATE & ADJUST TILT ANGLE Hang Vertical Rails with monitor attached Cuelgue con el monitor adherido. Accrochez avec le moniteur installé. Flat Panel Vertical Rails Pull spring lock cord down and gently push bottom of panel to wall and release...
- Page 11 STEP 4B - ADJUST THE SCREWS ON THE VERTICAL RAILS TO LEVEL THE FLAT PANEL Maximum leveling adjustment 0.5” STEP 4C - ADJUST STRAP LENGTH (OPTIONAL) STEP 4D - ADDITIONAL SECURITY FEAUTURE (OPTIONAL) Option Opcione Option Vertical Rails Flat Panel Wall Plate Vertical Rails have 7mm hole located at the...
-
Page 12: Warranty Information
WARRANTY INFORMATION This warranty applies to US Residents who purchase from an authorized RED ATOM Dealer. RED ATOM products are covered against defects in materials and workmanship for 5 years. RED ATOM will repair or replace the defective component or product, at its sole discretion. Failure to follow product care instructions from RED ATOM will result in void of warranty.
