Configuring your Saitek Pro Flight Yoke and Throttle Quadrant for
Microsoft Flight Simulator 9 and FS X
The Saitek Pro Flight Yoke System's buttons, controls and axes correspond to
commonly used functions in Microsoft FS 9 and FS X according to the tables below.
As with any software, if you wish to change the function of a button or control, you will
need to change the settings of the game software.
Function Overview
Button 1
POV
T1 = Button 3
T2 = Button 4
Chronometer display
Function Stopwatch/Clock
Stopwatch Start/Stop
05/09/2007 09:55 Page 6
Button 2
Mode Selector
T3 = Button 5
T4 = Button 6
T5 = Button 7
T6 = Button 8
Stopwatch Reset
6
Flight Yoke controls and corresponding functions in Microsoft Flight
Simulator
Function
Yoke axis X axis
Y axis
Main Buttons Button 1
T1 (button 3)
T2 (button 4)
T3 (button 5)
T4 (button 6)
T5 (button 7)
T6 (button 8)
Button 2
POV
Other Controls Mode switch
Clock Buttons Function
Start/Stop
Reset
Default function in FS 9 and FS X
Ailerons
Elevator
Brakes (apply/release)
Elevator trim down
Elevator trim up
Flaps retract incrementally
Flaps extend incrementally
Knee board display/hide
Landing gear up/down
Views (cycle)
Panoramic viewing
Switches Mode when using Saitek Smart
Technology (SST) programming software
Clock / stopwatch swap
Start/stop stopwatch
Reset stopwatch
