the quantity of chlorides be less than
30mg/l . Respecting these values allows
the machine to operate at maximum
efficiency. If these parameters are not
present, a specific filtration device should
be installed, while always adhering to the
local national standards in place regarding
potable water.
Then connect the inlet of the water filter/
softener (if present) to the drinking water
supply using one of the supplied stainless
steel braided hoses.
Before connecting
the filter to the main water supply, flush
the water supply line and the filtration
system in order to eliminate any residual
particles which could otherwise get stuck
in taps or valves thus preventing them
from working properly. Connect the water
supply connection of the steam module
using one of the supplied stainless steel
braided hoses. Then connect the steam
module inlet to the water filter/softener
outlet (if present).
16
7) Electrical connections
a) Power supply cord
• This is the main power supply cable
that provides power to the entire steam
machine:
• 200/220VAC 1 Phase 3-core cable with
1,5mm2 cross section
T.D.S.
Total Hardness
Total Iron (Fe
/Fe
)
+2
+3
Free Chlorine (Cl
)
2
Total Chlorine (Cl
)
2
pH
Alkalinity
Chloride (Cl
)
N.B.: Test water quality (the warranty is void if water parameters are not within the range
specified in the section "installation")
8) Waste water drain connection
The steam machine drain is to be connected
by means of the included reinforced plastic
tubings. Connect one end of the reinforced
plastic tubing to the drain hose connection
on the right side of the steam machine,
secure with included hose clamp. Connect
the other ends to a suitable waste water
collection system.
In case such a system is not available,
drained liquids may be collected in a
suitable bucket and any necessary drain pipe
extensions shall be made using steel-lined
PVC tubing and suitable hose clamps.
Water specifications table
Min.
ppm
90
ppm
70
ppm
0
ppm
0
ppm
0
value
6,5
ppm
40
ppm
not more
Max.
150
100
0,02
0,05
0,1
8,5
80
30
