060588-026 SL26/30SL
S
PECIFICATIONS
Specifications subject to change without notice. Refer to the Service Manual for service and repair infor-
mation. Refer to the Parts Manual for illustrated parts breakdown. Hot weather or heavy use may reduce
performance. Meets or exceeds all applicable national safety requirements
Page 18
All manuals and user guides at all-guides.com
ITEM
Platform Size (Inside toeboards)
Standard
Slide-out Deck Extended
Max. Platform Capacity
Standard
With Extension
on Extension
Max. No. of occupants
Standard
on Extension
Height
Working Height
Max. Platform Height
Min. Platform Height
Max. Drivable Height
Dimensions
Weight
Overall Width, Standard
Overall Height
Overall Length, Standard
Surface Speed
Platform Lowered
Platform Raised
System Voltage
Hydraulic Tank Capacity
Maximum Hydraulic System Pressure
Hydraulic Fluid
Normal Temp. above 0° C [32° F]
Low Temp. below 0° C [32° F]
Below -17°C [0° F]
Lift System
Lift Speed
Platform Leveling
Power Source
Fuel Tank Capacity
Drive Control
Control System
Horizontal Drive
Tires
Parking Brakes
Turning Radius (inside)
Maximum Gradeability:
Wheel Base
Ground Clearance
Guardrails
Guardrail
Bolt Torque
Noise Level
SL26SL
1,71 m x 3,59 m [67.5 in x 141.5 in.]
1,71 m x 4,61 m [67.5 in. x 181.5 in.]
680 kg [1500 lbs.]
680 kg [1500 lbs.]
227 kg [500 lbs.]
5 people
2 people
9,93 m [32 ft. 6 in.]
7,93 m [26 ft.]
1,5 m [59 in.]
7,93 m [26 ft.]
2,853 kg [6,290 lbs.]
2,13 m [84 in.]
2,60 m [102.5 in.]
3,79 m [149 in.]
0 to 5,0 km/h [0 to 3.1 mph]
0 to 0,8 km/h [0 to 0.5 mph]
12 Volt DC
45,5 liters [12 US Gallons]
193 bar [2800 psi]
ISO #46
ISO #32
ISO #15
One Single Stage Lift Cylinder
Raise: 21 sec. Lower: 32 sec.
13° side/side, 9° fore/aft
Diesel 20 HP Kubota, 3 Cylinder, Water
Cooled
47,5 liters [12.5 US gallons]
Proportional
Joystick controller with interlock lever
and thumb rocker steering, selector and
emergency stop switches; Leveling
control, two toggle switches and bubble
level (inoperable above interlock height)
4 Wheel, Hyd. Motors
26 x 12.00 - 12NHS Super Terra-grip,
foam filled
Dual Disc, Spring Applied
3,96 m [13 ft.]
19° [35%]
2,54 m [100 in.]
0,24 m [9.5 in.]
1,1 m [43.5 in.] high, fold down with
gate.
31Nm [23 ft. lb.]
SL30SL
1,71 m x 4,22 m [67.5 in x 166.25 in.]
N/A
590 kg [1300 lbs.]
N/A
N/A
5 people
N/A
11,14 m [36 ft. 6 in.]
9,14 m [30 ft.]
1,5 m [59 in.]
9,14 m [30 ft.]
2,967 kg [6,541 lbs.]
2,13 m [84 in.]
2,60 m [102.5 in.]
4,39 m [173 in.]
0 to 5,0 km/h [0 to 3.1 mph]
0 to 0,8 km/h [0 to 0.5 mph]
12 Volt DC
45,5 liters [12 US Gallons]
193 bar [2800 psi]
ISO #46
ISO #32
ISO #15
One Single Stage Lift Cylinder
Raise: 24 sec. Lower: 36 sec.
13° side/side, 9° fore/aft
Diesel 20 HP Kubota, 3 Cylinder, Water
Cooled
47,5 liters [12.5 US gallons]
Proportional
Joystick controller with interlock lever
and thumb rocker steering, selector and
emergency stop switches; Leveling
control, two toggle switches and bubble
level (inoperable above interlock height)
4 Wheel, Hyd. Motors
26 x 12.00 - 12NHS Super Terra-grip,
foam filled
Dual Disc, Spring Applied
3,96 m [13 ft.]
19° [35%]
2,54 m [100 in.]
0,24 m [9.5 in.]
1,1 m [43.5 in.] high, fold down with
gate.
31Nm [23 ft. lb.]
Operator Manual

Specifications
