Sleep Mode; General Specifications - EGAmaster EGATRONIK 51268 Manuel D'instructions

To preserve battery life, the Meter automatically turns off if you do not turn the rotary switch or
press any button for around 15 minutes. The Meter can be activated by pressing the SELECT button
or turning the rotary switch.
- Maximum Voltage between any Terminals and Grounding: 500V rms.
- Fused Protection for VΩmA Input Terminal: 500mA, 250V fast type, Ø5x20 mm
- 10A Terminal: Un-fused.
- Range: Auto ranging
- Maximum Display: Display: 3999.
- Measurement Speed: Updates 3 times / second.
- Temperature:
Operating: 0ºC~40ºC (32ºF~104 ºF).
Storage: -10ºC~50ºC (14ºF~122ºF).
- Relative Humidity: 75% @ 0ºC - 30ºC; 50% @ 31 - 40ºC.
- Altitude: Operating: 2000 m.
Storage: 10000 m.
- Battery Type: Two piece of 1.5V AAA Battery.
- Battery Deficiency: Display: .
- Negative reading: Display: "-".
- Overloading: Display: "0L".
- Dimensions (HxWxL): 130 x 73.5 x 35mm.
- Weight: Approx. 156g (battery included).
- Safety/Compliances: IEC61010 CAT I 600V, CAT II 300V overvoltage and double
insulation standard.
- Certification:
Accuracy: (a% reading + b digits), guarantee for 1 year.
Operating temperature: 23ºC -5ºC.
Relative humidity: <75%
All manuals and user guides at all-guides.com
(figure 7)

SLEEP MODE

GENERAL SPECIFICATIONS
