Epson PowerLite 83V+ Guide Rapide

PowerLite 83V+
®
Quick Setup
Before using the projector, make sure you read the safety instructions in the
User's Guide on your projector CD.
Connect the projector
Choose from the following connections:
Computer Monitor Port
Connect a computer using the VGA cable that came with the projector.
Connect one end to the projector's Computer1 port, and the other end to
your computer's monitor port. If you are using a notebook, switch it to
external display. You can also connect an audio cable.
External Monitor
Connect a monitor to the Monitor Out port.
Video Player
Connect up to 4 video devices and use the remote control to switch
between them.
S-Video RCA video cable
cable (composite video)
(optional) (optional)
*411830100*
*411830100*
Component
video to Computer
VGA cable cable
(optional) (included)
L-Audio-R
ports
Audio2 and Audio1 ports
Turn on your equipment
1
Turn on your computer or video source.
2
Plug in the projector.
The power light on the projector turns orange.
3
Open the A/V Mute slide all the way.
4
Press the power button on the projector or remote control.
The projector beeps, the
The projector lamp comes on in about 5 seconds.
NOTE: To shut down the projector, press the
unplug it. You don't have to wait for the projector to cool down.
Adjust the image
1
If you don't see an image, press the Source Search button on the
projector or remote control to select the image source.
NOTE: If you still see a blank screen or have other display problems, see
the troubleshooting tips on the right.
2
To raise the image, press the foot release button and lift the front of the
projector. Release the button to lock the foot in position.
power light flashes green, and then stays on.
power button twice, then
