Initial start-up

Assembling the trolley:
Fit the longitudinal axis to the drive axis (Fig. 1).
■
Fit the drive (rear) wheels: Push in the pin on the
■
wheel hub and click the wheel into place (Fig. 2).
Important: Click once = freewheel mode (smooth
manual operation). Click twice = motor mode. Ensure
that both wheels have been correctly fitted by liste-
ning for the number of clicks. The tire profiles should
face the direction of travel (like front wheel) (Fig. 2).
Attach the control arm and adjust to desired height
■
(Fig. 3).
Lower bag rest: Lift and turn in the direction of travel.
■
Upper bag rest: Click into desired position and secure.
■
Insert the battery into the holder and plug in the
■
cable (Fig. 4). The LED lights indicate the current
charge level (5 LEDs = full).
Scorecard holder: Screw onto the caddy frame with
■
the mounting clamp. Tighten the screws using the
Allen key (Fig. 5).
Umbrella holder: Fix to the handle in the desired
■
position using the locking screw (Fig. 6). The elastic
strap secures the umbrella in the wind.
Beverage holder: Screw on to the caddy frame.
■
Tighten the screws using the Allen key (Fig. 7+ 8).
Place your golf bag on the trolley and secure it
■
to the two holders using the elastic strap.
