JETVENT FANS SPECIFICATIONS
Model
Width
JVEC-LP
68 11/16 in
1745 mm
JVEC-SP
68 11/16 in
1745 mm
JVEC-SP-LV
68 11/16 in
1745 mm
JVEC-HP
74 1/8
1883mm
LAYOUT
This phase should have been completed prior to placing your order. If you do not have a plan or would like to consider
modifications, please consult with your professional engineer, designer and/or installer. You may also contact your Zoo
Fans' representative or Zoo Fans directly if you require assistance.
Remember, the number of JetVent Fans required for the job, as well as where they are hung, will depend on a number of
variables, some of which are:
•
Ceiling height, as well as the overall volume of air the fans need to move in order to achieve the targeted
level for turnover of air in the facility every hour
•
The availability of a sturdy and secure anchor point for attaching the fan
•
Obstructions
•
The location of existing HVAC supply and returns
Ask the electrician who will do the wiring for the fan(s) to review the following section to be sure your layout is a good one
for your objectives and that it is sensible given electrical requirements and any existing wiring. Ask the contractor who will
be hanging your fans to review your layout for ease and safety of installation, as well as compatibility with existing
mechanical systems and all applicable codes. If the installer(s) have any questions about where to locate your fan(s) or how
to install them, please contact either your Zoo Fans' representative or Zoo Fans. A copy of this installation guide can also be
found at jetventfans.com.
Weight
196.2 lbs
89 kg
196.2 lbs
89 kg
196.2 lbs
89 kg
in
352.7
lbs
160 kg
Amps
Voltage Range
2.9
380V – 480V 3Ph
2.9
380V – 480V 3Ph
4.9
200V – 400V 3Ph
4.8
380V – 480V 3Ph
2
Max RPM
Max CFM
1770
3178
1770
3475
1770
3475
1230
6145
