For inclined panel model, you need to drill 4 x 8 mm extra holes an use screw plugs
and screws befor installation.
Chimney Installation
1
Put the upper chimney into lower
chimney .Then pulling out the upper
chimney upwards. Adjust to reach the
height required.
Installation (Vent inside)
If you do not have an outlet to the outside, exhaust pipe is not required and the
installation is similar to the one show in section "Installation (Vent outside)".
2
2
Sliding the chimney to adjust the
chimney height. When the height you
required is reached, then hang the fixing
hole to the fixing screws as showed in
picture.
