ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Specifications
Headlamp: simple one-hand operation, reliable headmount. Solid body
without long wires, weak rubber connectors and unnecessary boxes.
The flashlight is easily installed, removed and 180° rotatable in the
mount
Every Day Carry light: compact design, convenient side button, spe-
cial matt anti-abrasive finish without rough knurling, strong built-in tail
magnet and robust removable steel clip
Bicycle light: body made from durable and lightweight aircraft-grade
aluminium, improved shock resistance, new springs for better bat-
tery and driver protection. Constant light without flickering, optional
quick-release mount
Keychain light: compact and lightweight for even more comfortable
carry in a pocket, hole for keyring or lanyard in the tailcap
Lamp mode: works without batteries directly from a Powerbank or any
USB adapter
• Multicolor temperature, battery level, charging process and state
indication with the ability to turn off the latter
• Convenient wide beam of fully upgraded optical system, TIR-lense
is protected from scratches by tempered glass with anti-reflective
coating
Model
LED/Optics
Brightness stabilization type
Light output
Peak beam intensity
Hotspot : Spill
Beam distance
Modes, light output and runtimes (measured with 18350 Li-Ion
900 mAh battery until the light output drops to 10% of the
initial value)
Power source
Length/Body diameter/Head diameter
Weight without/with battery
Submersion and Impact resistance
X Light output for flashlights with Warm light is about 7% less, beam distance is about 3% less.
All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are performed using the battery included in the set.
The data may vary due to environment, heat dissipation and other factors.
2 ENG USER MANUAL ELF C1
• Innovative technology allows using any 18350 Li-Ion batteries even
without additional protection circuit board
• Active real-time temperature control to prevent overheating
above +58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even at 10 meters depth.
Withstands fallings from up to 10 meters
• Robust and water resistant Micro USB socket even without rubber
cover
Set description
Flashlight, 18350 Li-Ion battery 900 mAh, Micro USB cable, clip, head-
mount, 2 spare O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
Elf C1 (White)
Samsung LH351D/TIR
DIGITAL (CPU brightness control)
1000 lm
2670 cd
70°:120°
103 m
Turbo
1000 lm/52 min (530 lm after 4 min)
Main3 500 lm/1 h 11 min
Main2 220 lm/3 h
Main1 40 lm/15 h
Firefly2 2 lm/8 d
Firefly1
0.11 lm/60 d
1x18350 Li-Ion
75.9 mm/20.4 mm/33 mm
56 g/81 g
IP68, 10 m for 2 h. Height up to 10 m
REV_00-0003
