Operation – Drill the Plugs
a. Cut the plug blanks 3-1/4" (83 mm) long in the intended direction of the
plug. For best results, use leftover scraps from your project to match
color and grain pattern.
b. Set the drill on the highest speed.
c. Clamp the blank securely in the Kreg Jig KPHJ720.
d. Insert the Plug Cutter Bit (B) into the Plug Cutter Drill Guide (A) holding
the Plug Cutter bit about 1/4" (6 mm) from the workpiece.
e. Start the drill and let it come up to full speed. Then, using light pressure
and a slow feed rate, slowly push the Plug Cutter Bit (B) until the stop
collar (C) contacts the Plug Cutter Drill Guide (A).
f. Withdraw the Plug Cutter Bit (B) from the Plug Cutter Drill Guide (A) taking
care as the Plug Cutter Bit (B) may be hot.
g. Release the clamp, reposition the blank, re-clamp securely, and repeat
for each plug.
6
C
B
A
