3" X 21" (76 x 533 mm)
BELT SANDER
3" X 21" (76 X 533 mm)
PONCEUSE À COURROIE
3" X 21" (76 X 533 mm)
LIJADORA DE CORREA
Instruction manual
Manuel d'instructions
Manual de'instrucciones
www.portercable.com
INSTRUCTIVO DE OPERACIÓN,
CENTROS DE SERVICIO Y PÓLIZA
DE GARANTÍA.
LÉASE ESTE INSTRUCTIVO ANTES
DE USAR EL PRODUCTO
N431737 APR15
The following are PORTER-CABLE trademarks for one or more power tools and accessories: a gray and black color
scheme; a
"four point star" design; and three contrasting/outlined longitudinal stripes.
DEFINITIONS - SAFETY GUIDELINES
indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
indicates a potentially haz ard ous situation which, if not avoided,
may result in minor or mod er ate injury.
used without the safety alert symbol indicates potentially
hazardous situation which, if not avoided, may result in property damage.
To reduce the risk of injury, read the instruction manual.
GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions Failure to follow
the warnings and instructions may result in electric shock, fire and/or
serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a ground fault
circuit interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of electric
shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energizing power tools that have the
switch on invites accidents.
352VS
Copyright © 2007, 2011, 2012, 2015 PORTER-CABLE
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and
gloves aPorterway from moving parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool's operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits, etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result
in a hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
ADDITIONAL SPECIFIC SAFETY RULES
• Hold power tool by insulated gripping surfaces, because the belt may contact its own
cord. Cutting a "live" wire may make exposed metal parts of the tool "live" and could give the
operator an electric shock.
• Do not sand metal of any kind with your sander. Sparks may be generated by sanding
screws, nails or other metals which may ignite dust particles.
• Do not wet sand with this sander. Liquids may enter the motor housing and cause electric
shock.
• Empty dust bag frequently. Especially when sanding resin coated surfaces such as
polyurethane, varnish, shellac, etc. The accumulation of fine sanding dust particles may self
ignite and cause fire.
• Do not operate this tool for long periods of time. Vibration caused by the operating action
of this tool may cause permanent injury to fingers, hands, and arms. Use gloves to provide extra
cushion, take frequent rest periods, and limit daily time of use.
• Sanding of lead-based paint, chemically pressure treated lumber or other materials
that may contain carcinogens is not recommended. Sanding of these materials should only
be performed by a professional.
• Clean out your tool often, especially after heavy use. Dust and grit containing metal
particles often accumulate on interior surfaces and could create a risk of serious injury, electric
shock or electrocution. ALWAYS disconnect the sander from the power source before cleaning.
ALWAYS WEAR SAFETY GLASSES that conform to ANSI Z87.1.
• ALWAYS disconnect tool from the power source before changing abrasive belts or
sheets. Such preventive safety measures reduce the risk of starting the power tool accidentally.
• ALWAYS maintain a firm grip with both hands on the belt sander handles with both
hands to prevent loss of control.
• ALWAYS keep fingers away from the moving belt and areas where the belt enters the housing
to avoid severe abrasion.
• Do not operate belt sander without all guards and covers securely in place.
• To avoid injury, do not use this tool in a stand that would invert it for use as a stationary
belt sander. This tool is not made for that application.
• Air vents often cover moving parts and should be avoided. Loose clothes, jewelry or long
hair can be caught in moving parts.
• An extension cord must have adequate wire size (AWG or American Wire Gauge) for
safety. The smaller the gauge number of the wire, the greater the capacity of the cable, that is
16 gauge has more capacity than 18 gauge. An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating. When using more than one extension to make up
the total length, be sure each individual extension contains at least the minimum wire size. The
following table shows the correct size to use depending on cord length and nameplate ampere
rating. If in doubt, use the next heavier gauge. The smaller the gauge number, the heavier the
cord.
Minimum Gauge for Cord Sets
Volts
Ampere Rating
120V
240V
More
Not More
Than
Than
0
6
6
10
10
12
12
16
ALWAYS use safety glasses. Everyday eyeglasses are NOT safety glasses. Also
use face or dust mask if cutting operation is dusty. ALWAYS WEAR CERTIFIED SAFETY
EQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratory protection.
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well ventilated area, and work with approved safety
equipment, such as those dust masks that are specially designed to filter out microscopic particles.
• Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling, and
other construction activities. Wear protective clothing and wash exposed areas with
soap and water. Allowing dust to get into your mouth, eyes, or lay on the skin may promote
absorption of harmful chemicals.
Use of this tool can generate and/or disperse dust, which may cause serious and
permanent respiratory or other injury. Always use NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles away from face and body.
Always wear proper personal hearing protection that conforms to ANSI S12.6
(S3.19) during use. Under some conditions and duration of use, noise from this product may
contribute to hearing loss.
• The label on your tool may include the following symbols. The symbols and their definitions are
as follows:
V .....................volts
Hz ...................hertz
min .................minutes
or DC .....direct current
...................Class I Construction
.......................(grounded)
...................Class II Construction
(double insulated)
.../min ............per minute
IPM .................impacts per minute
SPM ...............strokes per minute
Total Length of Cord in Feet (meters)
25 (7.6)
50 (15.2)
100 (30.5)
50 (15.2)
100 (30.5)
200 (61.0)
AWG
18
16
16
18
16
14
16
16
14
14
12
Not Recommended
A .........................amperes
W ........................watts
or AC .............alternating current
or AC/DC......alternating or direct current
n o .......................no load speed
n .........................rated speed
.......................earthing terminal
........................safety alert symbol
BPM ...................beats per minute
RPM ...................revolutions per minute
sfpm ...................surface feet per minute
150 (45.7)
300 (91.4)
14
12
12

Publicité

loading

Sommaire des Matières pour Porter Cable 352VS

  • Page 1 • Clean out your tool often, especially after heavy use. Dust and grit containing metal particles often accumulate on interior surfaces and could create a risk of serious injury, electric 352VS shock or electrocution. ALWAYS disconnect the sander from the power source before cleaning.
  • Page 2 To release the lock button, squeeze the trigger and release. VARIABLE SPEED Model 352VS has a Variable Speed Control. The operating speed is adjustable between 850 SFM (surface feet per minute) and 1300 SFM. The speed is adjusted by turning the variable speed dial (E) Fig. 2. The first position provides the slowest operating speed (850 SFM) while position 6 is the fastest (1300 SFM).
  • Page 3 CLEANING b) Ne pas faire fonctionner d’outils électriques dans un milieu déflagrant, tel qu’en présence de liquides, de gaz ou de poussières inflammables. Les outils électriques Blow dirt and dust out of all air vents with clean, dry air at least once a week. To produisent des étincelles qui pourraient enflammer la poussière ou les vapeurs.
  • Page 4 VITESSE VARIABLE Le modèle 352VS a une commande variable de vitesse. La vitesse de fonctionnement est réglable cet outil peut produire et/ou répandre de la poussière susceptible de causer des entre 850 SFM (pieds extérieurs par minute) et 1300 SFM. La vitesse est ajustée en tournant de dommages sérieux et permanents au système respiratoire.
  • Page 5 CONSERVE TODAS LAS ADVERTENCIAS E INSTRUCCIONES NETTOYAGE PARA FUTURAS CONSULTAS enlever les saletés et la poussière hors des évents au moyen d’air comprimé propre et sec, au moins une fois par semaine. Pour minimiser le risque de blessure aux El término “herramienta eléctrica” incluido en las advertencias hace referencia a las herramientas yeux, toujours porter une protection oculaire conforme à...
  • Page 6 La utilización de esta herramienta puede generar polvo o dispersarlo, lo que podría El Modelo 352VS tiene un Control de Velocidad Variable. La velocidad puede ajustarse entre causar daños graves y permanentes al sistema respiratorio, así como otras lesiones. Siempre use 850 PSM (pies sobre la superficie por minuto) y 1300 PSM.
  • Page 7 También puede escribirnos solicitando información a PORTER-CABLE, 4825 Highway 45 North, Jackson, Tennessee 38305; referencia: Mantenimiento de productos. Asegúrese de incluir toda la ESPECIFICACIONES información mencionada en la placa de la herramienta (número de modelo, tipo, número de serie, etc.) MODEL 352VS ACCESORIOS Tensión de alimentación: 120 V AC~ Consumo de corriente: Su proveedor de productos PORTER-CABLE, los Centros de mantenimiento de fábrica de...
