PANEL PXC48 > Inserting areas
Perimeter
Kitchen
Bathrooms
Bedrooms
06:13
Wednesday 01 March 2017
3
PANEL PXC48 > Perimeter > Inputs
Input 01
Input 02
06:13
Wednesday 01 March 2017
4
Interrupt
insertion
Force inserting
Home Back Settings
E
Insertion
Home Back Settings
Once inserting has been launched, only two buttons remain active .
Cancel inserting in progress .
Insert the areas immediately without respecting the exit time .

Displaying the status of an area's inputs

Select one of the available areas 1 to display the status of the inputs that it is made up of
4 .
Input included (if open, it triggers an alarm) .
Input excluded (if open, it does NOT trigger an alarm) .
Input open (not ready) .
Input closed (ready) .
There is a video camera at the input .
A sensor with a camera is connected at the input and can be used to take photographs
where activated; tap this icon to access the image database directly .
