REF PART NO. PRV NO.
1 86233150 20042
2 86279880 27425
3 86234780 27772
4 86238430 36191
5 86282040 39558
6 86050350 39482
7 86197940 40027
8 86004460 41333
9 86005750 57113
10 86006760 70305
11 86007000 70632
12 86007970 73864
13 86008250 75293
14 86233410 81270
15 86258720 84075*
16 86010670 87029
17 86005680 57047
18 86257310 73886*
19 86002800 270121
20 86009700 82267
21 86001600 40076
22 86197310 141045
23 86008400 78499
24 86002390 20063
25 86004310 39505
26 86010540 84141
27 86281990 39552
28 86197940 40027
29 86275370 70447
30 86279470 87165
31 86010650 87018
32 86077300 51406
33 86087350 730342
34 86255910 73659
35 86001590 40049
36 86270930 57065
37 86010660 87025
38 86005750 57113
39 86274920 70327
40 86075270 20108
41 86025960 47472
42 86003190 27890
- 86026950 84202
▲INCLUDES ITEMS: 86068510-PRV NO. 40027, 86275370-PRV NO.70447, 86279470-PRV NO. 87165,
86010650-PRV NO. 87018, 86077300-PRV NO. 51406, 86087350-PRV NO. 730342, 86001590-PRV NO.
40049, 86197310-PRV NO. 141045, 86258720-PRV NO. 84075, 86257310-PRV NO. 73886
* SEE SERIAL NUMBER PAGE
All manuals and user guides at all-guides.com
SOLUTION TANK GROUP – NON-TRACTION
QTY DESCRIPTION
5 CLAMP, 3/8 HOSE (D-SLOT)
1 CORD, SOLUTION COVER
1 COVER, SOLUTION TANK
2 GROMMET 1.00 ID 3/16 GRIP
1 HOSE, 1/2 ID NYLOBRAID X 40"
1 HOSE, 1/2 ID NYLOBRAID X 15"
1 HOSEBARB, 3/8MPTX1/2 90D DL
2 HINGE, SCRUBBER TANK
2 NUT, 5/16-18 HEX NYLOCK
4 SCR, 5/16-18 X 3/4HHCSGR5PLTDL
2 SCR, 5/16-18 X 3/4 FHSCS BLKZC
1 STRAINER, 3/8 IN. NPT 60 MESH
1 TANK, SOLUTION
2 CLAMP, 3/4 DIA CUSHION .406DIA
1 VALVE, 3/8 FPT BALL
3 WASHER, 5/16 FLAT SS
4 NUT, 1/4-20 HEX NYLOCK
1 SWIVEL, SOLUTION CABLE
1 CABLE, .062 X 43 SS PUSH/PULL
1 PLUG, 5/8" DRAIN HOSE
1 SLEEVE .63 ID X 1.0 OD
1 BUSHING, 3/8 X 3/8 NPT (F18-3)
1 TETHER, DRAIN PLUG
2 CLAMP, 1.75" WORM GEAR X .312
1 HOSE, 1.0 X 18.0 DRAIN
1 VALVE, 24VDC SOL. 1/2" HOSEBARB
1 HOSE, 1/2 ID NYLOBRD X 4"
1 HOSEBARB, 3/8 MPT X 1/2 90D DL
1 SCR, 10-24 X 1/2 FHTC
1 WASHER, #10 SPLIT LOCK PLTD
1 WASHER, #10 X 9/16 OD
1 LEVER, VALVE
1 SPACER, VALVE
1 STANDOFF, 1/4-20 X 1.0 HEX INS
1 HOSEBARB, 3/8 MPT X 1/2 NYLON
1 NUT, 1/4-20 JAM SS
1 WASHER, 1/4 LOCK EXT STAR SS
2 NUT, 5/16-18 HEX NYLOCK
1 SCR, 1/4-20 X 3/8 PTHMS PL
1 CLAMP, VALVE
1 VALVE, SOLUTION
1 CABLE, .062 X 41 SS PUSH/PULL
- VALVE ASM, 3/8 FPT BALL
SABER (QSC) 86037050 03/20/08
SERIAL NO.
FROM NOTES:
*(8)
*(3)
*(8)
*(8)
*(3)
*(3)
*(3)
*(3)
*(3)
*(3)
*(3)
WAS 84167
▲
5-26
