(4) Full Screen: Resizes the live view display to fit to the monitor resolution. ESC key
returns to the previous view.
(5) Custom: Selects the live view display scale, 0%~200%, by the control bar. 100% is
the original size.

PTZ Control

ZOOM : Controls the lens optical zoom in/out for WIDE & TELE.
FOCUS : Adjusts the lens focus manually for NEAR & FAR.
PUSH AF : Gets the lens to focus at the push of a button.
ZOOM, FOCUS & PUSH AF are disabled when PTZ control is locked. PTZ control can
i
be unlocked at Setup>Video&Image>Image>AF>Lens Locking to OFF or TIMER.
CAUTION: Set LENS LOCKING at Setup>Video&Image>Image>AF>Lens
Locking to ON or TIMER after completing lens setting to prevent unwant-
ed lens operation.
Do not adjust zoom/focus in low light conditions or night mode. It might
cause erroneous focusing.
For Motorized V/F versions, Zoom/Focus operation is strongly recom-
mended for installation purpose only. Frequent zoom/focus adjustments
can reduce the life span of the lens.

Setup Menu Table

Category Menu
Player Control
LIVE VIEW Video Stream
Protocol
PTZ Control
Configuration
Pause, Snapshot
Display (Window Fit, Full Screen, Custom)
Stream1, Stream2, Stream3
HTTPS, HTTP, TCP, UDP
Zoom, Focus, Push AF
