General Instructions
Faucet Installation:
1. Shut off water supply and drain lines.
Drill a hole approximately
1-1/4" diameter in countertop where
you are installing no.1.
2. Loosen no.14 with a 1-15/16" wrench
and separate the two sections.
Note: Dont turn no.14 any
further after disassembly.
11
12
3. Remove no.12 and no.11 from
no.1.
4. Place no.1 through hole in sink,
align hot and cold sides parallel to sink
line
1
14
sink
13
5. Install no.11 and no.12 on no.1,
tighten no.12. Screw no.14 up on no.1,
tightening by hand, making sure to
align pins on no.13 with corresponding
holes at base of no.1.
Note: If no.13 and no.1 are
joined correctly, the no.13 will not
move or twist if tried.
1
6. Tighten no.14 with a 1-15/16"
wrench.
7. Connect supply lines and check for
leaks.
Caution: Turn off water supply at
base faucet when not in use.
4
1
11
12
