STEP 1 - PREP THE WALL
There are two types of electrical options available for vanities. The first is a night light option ordered with the vanity. The second is an
electrical accessory [VAELECTRIC]. Both of these options can be plugged into the same outlet.
The outlet must be wired to a 120vac 20 amp GFCI circuit. We do not recommend using a GFCI outlet because resetting it under the
vanity will be inconvenient.
The night light has no switch. A switch can be wired to one receptacle in the outlet to operate the night light or, for a seamless
experience, an occupancy sensor can be installed near the doorway to the bathroom.
All applicable electrical codes in your area must be followed.
The outlet can be installed to the left or right of center depending on which side the VAELECTRIC accessory will be located.
Plumbing should be located as shown to prevent interference with the vanity drawers.
Supply
11-3/16"
(284 mm)
© 2017 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376
www.robern.com
Installation instructions
8"
(203 mm)
6-1/8"
(156 mm)
Plumbing drawer clearance
4
Drain
11-5/8"
(295 mm)
22"
(559 mm)
Part no. 209-1276-rA rev. 06/16/17
Curated Cartesian H2 - 3 Drawer
