SAFETY AND GENERAL INFORMATION
Save these instructions. For your safety, read, understand, and follow the information provided with and on this
device before using. The owner and/or operator shall have an understanding of the device, its operating characteristics
and safety operating instructions before operating the equipment. The owner and/or operator shall be aware that use
and repair of this product may require special skills and knowledge. Instructions and safety information shall be read
to and discussed with the operator in the operator's native language, making sure that the operator comprehends
their contents, before use of this equipment is authorized. If any doubt exists as to the safe and proper use of this
device, remove from service immediately.
Inspect before each use. Do not use if abnormal conditions such as cracked welds, damaged, loose or missing
parts are noted. Any equipment that appears damaged in any way, is found to be worn, or operates abnormally shall
be removed from service until repaired. If the equipment has been or is suspected to have been subjected to an
abnormal load or shock, immediately discontinue use until inspected by a factory authorized repair facility (contact
distributor or manufacturer for list of authorized repair facilities). It is recommended that an annual inspection be
made by an authorized repair facility. Labels and Operator's Manuals are available from the manufacturer.
Study, understand, and follow all instructions before operating this device.
Do not exceed rated capacity.
Use only on hard, level surfaces.
Adequately support the vehicle before starting repairs.
Use of this product is limited to removal, installation, and transportation in the
lowered position, of transmissions, transfer cases and transaxles.
No alterations shall be made to this product.
Only attachments and/or adaptors supplied by the manufacturer shall be used.
Failure to heed these markings may result in personal injury and/or property
damage.
PRODUCT DESCRIPTION
The Hydraulic Transmission Jack is designed to be used as an aid in the removal and installation of automotive and
light truck transmissions, transfer cases and transaxles. This telescopic style transmission jack is for use under an
overhead lift or in a garage pit. For air option model ATD-7431, ensure that your air source can dedicate 7.8 CFM
@ 110-175 psi to each jack operated.
SPECIFICATIONS
Model
Capacity
ATD-7430
1,000 lbs.
ATD-7431
!
Min.
Max.
Saddle Base
Height
Height
39-7/8" 77-1/4" 9-7/8" x 9-7/8"
WARNING
Expanded
Saddle Area
21" x 21"
11-1/2" x 11-1/2" 34-1/2" x 34-3/8"
2
Saddle
Jack Size
Area Min.
(L x W)
Weight
180 lbs.
194-1/2 lbs.
