8.2 Liste des pièces
N° Désignation (ENG)
1 Main frame
2 Left handlebar post
3 Right handlebar post
4 Handlebar
5 Base tube
6 Connecting tube
7 Allen bolt
8 Spring washer
9 Flat washer
10 Allen screw
11 Flat washer
12 Running belt
13 Wooden board
14 Side plate
15 Buffer bar
16 CSK inner hexagon screw
17 Buffer 1(red)
18 Buffer 2(blue)
19 Buffer 3(black)
20 Buffer 4(black plated)
21 Roller
22 Buffer
23 Nylon nut
24 Metal clip
25 Screw
26 Motor cover fixing plate
27 cable tie base
28 Screw
29 Fixing plate
30 Motor
31 Allen bolt
Référence pièce fab.
261D8-3-1000-J0
26100-3-1300-J2
26100-3-1400-J2
261D8-3-1500-B20
26100-3-1600-J2
26100-3-1900-J1
50108-5-0020-F0
55108-2-1520-FA
55108-1-2520-FA
54008-5-0030-F0
55108-1-1612-FA
261D8-6-1072-B0
26100-6-1073-B0
261A2-6-1076-B0
26100-6-1084-B0
51608-5-0025-F0
26100-6-1081-R0
26100-6-1082-K0
26100-6-1083-B0
26100-6-1088-F0
26100-6-1087-B0
23800-6-1272-04
55208-1-2008-FA
26100-6-1086-N0
52842-2-0015-F0
26100-6-1090-00
26100-6-1089-00
50904-2-0015-N0
816S0-6-1673-N0
26100-6-1085-03
50308-5-0015-F0
Spécification
M8x1.25x20L
D15.4xD8.2x2T
D25xD8.5x2T
M8*1.25*30L
D16*D8.5*1.2T
520*2.5T*3200L
1400*625*18T
92.7*39.2*1430L
25*2T*1380L
M8*1.25*25L
D30*37L*M8,45degree
D30*37L*M8,75degree
D30*37L*M8,95degree
D30*37L*M8,full metal
D65*24
D33*D44*34.5
M8*1.25*8T
D27*D4.3*2T
ST4.2*15L
32*18*18
15*10
ST4*1.41*15L
30*27*4T
DC-3.5HP
M8*1.25*15L
Nbre
1
1
1
1
1
1
8
12
8
4
5
1
1
2
2
8
2
2
2
2
4
2
12
10
80
4
5
6
2
1
6
37
