6. DEVICE CONFIGURATION

Refer to the system technical manual in the Manuals area for confi guration of the device.
Technical Manuals / Communication / Ipercom System at www.urmet.com.
You are advised to remove the QR code label from the front of the device and place it on the front
panel fi lm so that the QR code can be scanned during confi guration.

7. HOW TO REBOOT/RESET DEFAULT SETTINGS

Press the RESET button (10) once for a short time to reboot the device. LEDs (1) will fl ash once to confi rm
the operation.
Quickly press the RESET button (10) fi ve consecutive times (less than 1 second apart) to restore to default
settings and cancel all confi gurations made. LEDs (1) will fl ash 5 times to confi rm the operation.

8. SPEAKER VOLUME ADJUSTMENT

Volumes are calibrated by default so not to require adjustments in most cases.
Use a screwdriver to adjust the speaker volume (15), if required.
9. DDA (Disability Discrimination Act) LED ACTUATION
- SYSTEM STATUS INDICATION
The system state is shown by the following indications which appear on the door unit front:
a) call in progress: LED
b) line engaged: LED
c) off-hook waiting time expired: voice message "THE USER IS NOT ANSWERING";
d) conversion in progress: LED
e) conversation paused by the switchboard: LED
f) door open: LED

10. PEDESTRIAN LOCK ACTUATION

The door unit has two terminals for managing the pedestrian door lock (SE+ and SE-). The electric lock is
operated in the following cases:
• whenever the hall button is pressed (terminals PA, CT);
• when a door open command is received from an apartment station according to the confi guration
("free" or "privacy").

11. GARAGE GATE LOCK ACTUATION

The audio and audio-video door units have two terminals (SE2) connected to the contacts of a normally
open relay which can be used to control a gate opening control unit (*). The relay is operated for 1 second
after receiving the garage door opening command according to the operating mode ("free" or "privacy") as
the door lock.
(*) The relay is NOT suitable to control direct power loads and can only be used as control relay.

12. INSTALLATION CONSTRAINTS

Some installation constraints must be respected for installing the panel. The following are allowed for each
confi guration:
Panel with button modules
• A total maximum number of 12 installed modules;
• One IP audio video door unit module ref. 1060/48;
• A single ILA and voice synthesis module Ref. 1168/48;
• A single proximity key reader module Ref. 1168/45;
• Maximum insertion of 11 four-button expansion modules Ref. 1168/4 or eight-button modules Ref.
1168/8;
• Maximum insertion of 11 door number modules Ref. 1168/50
DS1060-148
on green and voice message "CALL IN PROGRESS"
on red and voice message "THE LINE IS BUSY"
on orange;
green and "THE DOOR IS OPEN" voice message.
on green and LED fl ashing orange.
