10- RISKS
10.1. Depending on the products used, there may be danger of fire; avoid smoking and open flames while spraying potentially flammable
products.
10.2. Danger of ejection of the adjustment handwheel: do not exceed the specified adjustment limits.
11- TROUBLESHOOTING
PROBLEMS
The gun does not spray when control
trigger is pressed
Irregular spraying
Difficulty is screwing on the cartridge
12- MAINTENANCE
12.1 Disconnect the spray gun from the supply.
12.2 Empty out the product from the spray gun, or remove the container cartridge.
12.3 Pour into the tank the necessary amount of thinner (usually ½ litre) suitable for cleaning the product being used.
12.4 Close the tank and connect the spray gun again.
12.5 Spray the solvent, directing the jet into a special container.
Make sure that the air-product adjustment handwheel is completely closed to avoid atomization of the solvent which may lead to pollution of the
nearby environments.
Do not immerse the spray gun completely into the solvent, but rather clean it with a brush or a cloth
12.6 In case the product leaks out around the needle and stuffing box screw, in front of the trigger (see fig. 1 point 13), clean the fouled parts immediately, turn
the stuffing box screw clockwise so as to hermetically seal the stuffing box installed in spray gun. This will prevent the product from leaking again. Finally, make
sure that the closing needle remains free to move.
12.7 Whenever necessary, lubricate the needle at the height of the stuffing box screw.
12.8 Occasionally, lubricate the air valve rod.
When the spraying job is finished, or during a pause , hang the spray gun on the special hook
A clogged spray gun may damage the cartridge. Always keep the nozzle and suction clean.
13 - WARRANTY
The quality of the goods supplied is covered by a guarantee and any part acknowledged to be faulty by our Engineering Department will be replaced free of
charge if it has not undergone misuse, is not soiled and has been delivered freight prepaid to our works.

14 - SAFETY WARNINGS

14.1 Danger of fire or explosion
Do not use solvents and/or halocarbon based detergents ( 1.1.1 Ethyl trichloride, Methyl chloride, etc.) since they could rust galvanised parts causing
even explosive chemical reactions. Neve use acidic or alkaline substances for cleaning (basis, paint removers, etc.)
Do not smoke or produce sparks: this could cause fire.
Always be sure that the painting equipment is earthed correctly.
14.2 Healt safety equipment and precautions
Use the spray gun only in well ventilated rooms.
Always wear suitable protective gloves and goggles as well as specific breathing filters/masks.
Use special clothing to protect the body from contact with toxic vapours, solvents or with the product in use.
The use of some paint products containing organic solvents can cause intoxication due to the toxic fumes they emit. In every case, it is necessary to
read the technical sheets for the products before use.
14.3 Warning concerning improper use
After cleaning, maintenaince and/or repairs and, in any case, before using the spray gun, make sure nuts and bolts are firmly secured in their housings.
NEVER exceed the rated pressure
14.4 General risk
The product must be not used if it has been subjected to potential damage following a bang or a fall which may have compromised its resistance, in
particular regarding endurance, adjustament or pressure parts.
Negative effects may not be immediately visible in terms of fractures, cracks or other similar effects. If any of the said events occur do not use the pro-
duct, but have inspections and testing carried out on it before making it work.
If you have any doubts please contact the salesman or the assistance before using the product.
CAUSES
No supply
Supply tube dirty or clogged
The cartridge aluminium shield is
not properly opened
CORRECTIVEACTIONS
Open the flow(fig.3point4) or the hand wheel(fig.3point2)
-
clean all ducts and spraying nozzle
-do not tilt the spray gun at an angle greater than 45°
En large with instrument or with the tube of the same spray gun
9
RC129 - English
