ENG
3.

Mounting

CAUTION
Risk of injury caused by a falling or
tilting light.
Personalinjuryandmaterialdamage.
X Mountfasteningelementscorrectly.
3.1 Mounting the fastening
elements
Fig.1:Fastening element, screw-type fas-
tening.
X Screw the fastening element to the
mounting surface using four suitable
screws.
3.2 Mounting the light to the
fastening element
Fig.2:Mounting the light to the fastening
element.
20
NOTE:Thescrew Bonthesideofthe
fasteningelementcanbeusedtomake
the opening of the fastening element
largerorsmaller.
X InsertthestudAonthelightsupport
into the opening of the fastening ele-
ment,seeFig.2.
X TightenthescrewBtofixthesupport,
seeFig.2.
3.3

Mounting the magnifier cover

CAUTION
Fire risk when the magnifier is not
covered and exposed to sunlight.
Personalinjuryandmaterialdamage.
X When the magnifier is not used,
coveritwiththemagnifiercover.
Fig.3:Mountingthemagnifiercover.
X Compresstheupperpartofthemagni-
fiercover,seeFig.3.
X Placethemagnifiercoveronthemag-
nifierfromaboveandreleasethecover.
Themagnifiercoverisclampedtothe
A
lighthead.
B
