Manual Door intercom devices a / b series 20 / 30 / 40 / 50 / 20-0028A/-0028B
GB GB
Configurations and Set-up
Code Parameter
19 = activation according to a schedule
(or manually, cf. configuration step 44) (V1.30 or later)
20 = activated after answering an emergency call (according to EN 81-70)
(V1.40 or later)
21 = activated when speaking in two-way communication (V1.42 or later)
22 = activated when listening in two-way communication (V1.42 or later)
23 = controls the additional relay board (V 1.51 or later)
24 = IP video routing (V1.61 or later)
Relay 2 activation time: Default setting: 5
13 1 = 1 second
2 = 2 seconds
:
30 = 30 seconds (up to V1.60)
:
90 = 90 seconds (V1.61 or later)
Relay 2 activation codes: Default setting: cf. configuration step 12
14 1. Activation code
15 2. Activation code
Activation codes consist of digits only and each activation code may be up
to 4 digits long.
76
Confirmation
#
#
#
#
#
#
#
#
:
#
