WARNING: Electrical wiring must be done by a qualified person(s) in
accordance with all applicable codes and standards. This range hood must be
properly grounded. Turn off electrical power at service entrance before wiring.
1) Prepare electrical wiring and ducting in cabinet. Location of junction box and blower outlet can be found on page 8.
Fig.3
2) Unscrew the (10) screws from front panel and place
the panel aside, Fig.3. You will now have access to the
interrior of the range hood.
Fig.5
4) There are spring clips located on the left and right sides
of the hood body which will temporarily hold the hood in
place, Fig.5.
3) Open cabinet doors. Lift range hood and slide it through
the opening located in the bottom of the cabinet, Fig.4.
Fig.1.
angle or 2" long Philips head screwdriver.
10
www.zephyronline.com
Fig.4
2
1
Fig.6
