GB
H05RR-F 4x4 CEI-UNEL 35363
H05VV-F 4x4 CEI-UNEL 35746
H05RR-F 5x2.5 CEI-UNEL 35363
H05VV-F 5x2.5 CEI-UNEL 35746
• Secure the power supply cable by fastening the
cable clamp screw then put the cover back on.
Connecting the supply cable to the electricity mains
Install a standardised plug corresponding to the load
indicated on the appliance data plate (see Technical
data table).
The appliance must be directly connected to the mains
using an omnipolar switch with a minimum contact
opening of 3 mm installed between the appliance and
the mains. The switch must be suitable for the charge
indicated and must comply with current electrical
regulations (the earthing wire must not be interrupted
by the switch). The supply cable must be positioned
so that it does not come into contact with temperatures
higher than 50°C at any point.
Before connecting the appliance to the power supply,
make sure that:
• The appliance is earthed and the plug is compliant with
the law.
• The socket can withstand the maximum power of the
appliance, which is indicated by the data plate.
• The voltage is in the range between the values
indicated on the data plate.
• The socket is compatible with the plug of the
appliance. If the socket is incompatible with the
plug, ask an authorised technician to replace it. Do
not use extension cords or multiple sockets.
! Once the appliance has been installed, the power
supply cable and the electrical socket must be easily
accessible.
! The cable must not be bent or compressed.
! The cable must be checked regularly and replaced
10
400V 2N~
N L2 L1
400V 3N~
N L3 L2 L1
by authorised technicians only.
! The manufacturer declines any liability should
these safety measures not be observed.
We recommend cleaning the oven before using it for
the first time, following the instructions provided in the
„Care and maintenance" section.
TABLE OF CHARACTERISTICS
Oven dimensions
32x43.5x39,5 cm
(HxWxD)
Volume 65 l
Useful
width 46cm
measurements
depth 42 cm
relating to the oven
height 8.5 cm
compartment
see data plate
Data plate, is located inside
the flap or, after the oven
Voltage and
compartment has been
frequency
opened, on the left-hand wall
inside the oven.
Ceramic hob
Front Left 1700 W
Back Left 1200 W
Back Right 2100 W
Front Right 1200 W
Max. ceramic hob 6200 W
consumption
Directive 2002/40/EC on the
label of electric ovens.
Standard EN 50304
ENERGY LABEL
Natural convection energy
consumption
heating mode:
This appliance conforms to the
following European Economic
Community directives:
2006/95/EC dated 12/12/06
(Low Voltage) and subsequent
amendments - 2004/108/EC
dated 15/12/04
(Electromagnetic Compatibility)
and subsequent amendments -
93/68/EEC dated 22/07/93 and
subsequent amendments.
2002/96/EC
1275/2008 (Stand-by/Off mode)
Static
