INSTALLATION - DKN CLOUD WI-FI ADAPTOR FOR VRV/SKYAIR (AZAI6WSCDKA)

Package content

Wiring cable for power supply and P1P2 communication
Modbus port
Indoor unit port for wiring cable
Wi-Fi connection reset
Account association reset
https://dkncloudna.com/modbus/MI_AZAI6_MODBUS_A4_MUL.pdf

LED Operation

The DKN Cloud Wi-Fi Adaptor have integrated LEDs that detects the operation of the device.
Depending on the LED operation, it indicates:
1. Off. Wi-Fi not configured.
2. Blinking green. Connecting to Wi-Fi network.
3. Steady green. Connected to Wi-Fi network.
4. Steady blue. Connected to the server.
Blinks red to indicate the cloud communication.
Blinks green to indicate microprocessor performance.
Stays red to indicate that the device is on.
Blinks red to indicate the data transmission to the indoor unit.
Blinks green to indicate the data reception from the indoor unit.
16
Meaning
