Adv Menu 26– Pallet Input Selection Enable
Adv Menu 26 – Pallet I/P Selection
I/P 1-6 Only
This menu determines which inputs can access the Pallet
I/P 1-6 Only Program Main and Alt inputs from the TMC1-Penta2 programs and load
inputs 1-4 from the pallet.
I/P 1-7 Only Program Main input from the TMC1-Penta2 programs and load input
inputs 1-6 and the Alt Input from the pallet.
All Inputs All inputs including Main and Alt can all be loaded from the pallet (Note
any Main or Alt setting will be lost until loaded from TMC1-penta2
software.
The main reason for the separation is to allow Atmos and other immersive systems to have
extra wide inputs, the maximum width for inputs 1-4 is 12 channels.
Adv Menu 27 – Write I/O Names to Penta / DAD AX/DX32
Adv Menu 27 – Write I/O names to Penta/DAD
The TMC-1 writes the I/O labels to the Penta/Dad/MTRX on power-up, each Name begins
with 'T', users who wish to write their own names can disable this function.
Note: the internal summing points are still named.
Adv Menu 28 – Reset Penta/DAD AX/DX32 to Defaults on Menu Exit
Adv Menu 28 – Reset Penta/DAD on Menu Exit
The TMC-1 controls the digital levels and routing within the DAD AX32/Penta. To prevent
interaction with PentaMan and DADMan the TMC-1 only controls the ports that you have
assigned to it. If you reassign inputs or outputs they can be left disabled or not set to unity
gain.
Off: No Action
Reset to Default: Reset DAD AX32/Penta to default and restart the TMC-1
Note1: Reset takes about 15 seconds, the TMC-1 must then be restarted, one easy way is
to reselect the Penta/DAD from the ENET/NTP Units Page.
2018 CB Electronics
TMC-1 Manuel de référence
I/P 1-7 Only
On
Off
56
All Inputs
off
Reset to Default
Version 7
