Safety edge
Option „wireless radio transmission"
Technical data ROLENTO
Dimension
Protective system - box
Operating voltage
max. possible power input of drive motor
Fuse - motor
Fuse - illumination
Internal illumination
Luminous period of interal illumination
Terminal of external warning light
Type of safety edge
Type of light barrier
Radio frequency
Teachable hand-held transmitters
Usability - radio control
Conformity
Working temperature
Weight
Safety edge, option „wireless radio transmission"
EU manufacturer's declaration
No helix cable necessary. A battery-operated transceiver is placed at the door's bottom slat and a pluggable
transceiver module is plugged in the control unit. The signals are wireless transmitted from the safety edge to
the control unit (2,4GHz).
Once detected that the battery is going flat, the following flashing signal is shown during every CLOSE move:
2x _ 2x _ 2x _ ... Door closes latching, but the transceiver batteries have to be replaced. In case the batteries
are completely discharged, the door can be closed by dead man's handling only.
Function check of wireless transmission between safety edge and control unit:
press and keep PROG button depressed on the battery-operated transceiver which is placed at the
  
door's final slat
LED on transceiver is lit => 
  
The receiver's radio range is limited to 10m. Walls or major metallic objects between the transreceiver and the
control unit may restrict the radio range even further.
control unit
®
295 x 150 x 81 (lxbxh)
IP20 (only in closed dry rooms)
230V AC / 50Hz
600W
2,5 A time-lag fuse
1 A time-lag fuse
230V AC / 15W / holder E14
3min
230V AC / max. 40W
electric (8,2kOhm) or optic
2-lead light barrier, manufacturer Sommer
868,8MHz (Keeloq)
112
Only sequential operations UP-STOP-DOWN-STOP-...
EN 12453:2005-5
EN 61000-6-3:2007-9
EN 61000-6-2:2006-3
EN 60335-1:2007
Directive sur basse tension 2006/95/EC
Directive EMV 2004/108/EC
-20°C bis +50°C
approx. 0,8kg
Radio frequency 2,4GHz
2 lithium batteries type AA 3,6V
Battery service life approx. 2 years
see www.roma.de
