MACHINE OVERVIEW

3
4
11
9
1. CUTTING HEAD HANDLE
2. MITRE ANGLE SCALE
3. UPPER BLADE GUARD
4. SLIDING FENCE
5. LOWER BLADE GUARD
6. ROTARY TABLE
1
7 6
7. MACHINE BASE
8. MOTOR HOUSING
9. MOUNTING HOLE (x4)
10. BLADE THROAT
11. SIDE CARRY HANDLES
