NO Connector
1 3-pin terminal
block
2 2-pin terminal
block
3 5-pin terminal
block
4 4-pin terminal
block
5 BNC jack

Product description and connections

Wire color
Red
White
Green
Blue
Gray
Violet
Orange
Sky Blue
Black
Yellow
Black & White
Sky Blue & Black ALARM OUTPUT 2
Orange & Black
Blue
Description
24VAC or 12VDC+
24VAC or 12VDC-
RS-485+
RS-485-
ALARM INPUT 1
ALARM INPUT 2
ALARM INPUT 3
ALARM INPUT 4
GND
ALARM OUTPUT 1
GND
GND
HD-SDI Output
