*Note: Be sure to load only the software listed for your unit specifically
There are detailed instructions on how to update your unit's software located
on the iKEY-AUDIO Web site, however here is a quick guide:
*Note: It is very important to that your unit does not lose power while updat-
ing the software, which can take up to several minutes. A loss of power to
your unit during an update can result in damage to your unit.
1) Ensure that the software update located online is most up to date
version, and that it is not currently running on your unit.
2) Unzip and download the latest software version onto the root
directory of your SD card.
3) Load it onto your unit making sure it is first powered off and then
turn it on.
4) The software will update automatically.

Specifications

Channels.................................................. 2 (stereo)
Recording Format:.................. MP3: 128, 256, 320 Kbps;
Recording Media.................................... SD (64 MB-2GB)
USB compatibility.................................. USB 1.0, 1.1, 2.0
Sampling Rate:......................................... 44.1kHz, 16 Bit
Dynamic Range: ..................................................... 98 dB
THD+N:.................................................................. -91 dB
Freq Response:.......................................... 20Hz – 20KHz
Input Impedance:...................................... Line: 10K Ω
Nominal Input Levels:............ Low Gain: 1V RMS (0 dBV)
High Gain: .13V RMS (-17 dBV)
Maximum Input Levels:..... Low Gain: 2.5V RMS (+8 dBV)
High Gain: .25V RMS (-12 dBV)
Output Impedance:............................................... 30 Ω
Maximum Output:......... Line (10K Ω): 0.7V RMS (-3 dBV)
Phones (32 Ω): 0.35V RMS (-9 dBV)
Power Source.................................... 1000mA DC adaptor
Weight: 5.29Lbs/2.4kgs
Dimensions (W x H x D): 19" x 1.75" x 9.96"
Dimensions (W x H x D): 483 x 45 x 253 mm
Please register your warranty online at
www.ikey-audio.com
Especificaciones • Caractéristiques techniques • Technische Daten
WAV: 44.1 kHz
SDHC (4 GB-32GB)
Any supported FAT-USB drive
Mic: 1K Ω
Mid Gain: .5V RMS (-6 dBV)
Mid Gain: .68V RMS (-3 dBV)
Specifications
