iKEY-AUDIO RM3 Manuel D'instructions page 11

The Input Gain switch (21) is also used to get a maximum signal
level. The switch changes the overall level of an incoming signal
between 3 padded levels: –20 dB [-], 0 dB [o] and +10 dB [+]. If
a signal is too low, try to raise it by switching from [-] to [o] or [o]
to [+]. If a signal is too high, try to lower it by switching from [+] to [o] or [o]
to [-].
Input Level
Signal Meters
Solution- Slightly scale back Rec. Level jog wheel so the meter does not appear red
Solution- Raise the Rec. Level jog wheel all the way and lower the input gain until the
signal barely peaks and can be scaled back so it does not appear red
Solution- Turn the Rec. Level jog wheel all the way up and raise the input gain until the
signal barely peaks and can be scaled back
*Note: If your recording is not being stored correctly, you may have to raise
or lower the signal coming from your source directly if possible.
Output Result
clean
recording
clipping/ distortion
clipping at mid-
recording level
low level
recording
Recording a File
*Note: Due to limitations in the FAT file system, when a recording file exceeds 2
GB in length, it will continue recording as a separate file.
Once your bit rate format, levels and stereo/mono settings have been made,
you are ready to record. In record mode, simply press the RECORD button to
start recording. A light will flash below the record button to indicate that the
unit is recording.
To pause a recording, press the RECORD button again.
To continue a recording, press the RECORD button once more.
To stop recording, and return to the previous menu, press the STOP/BACK
button (*Note: Files that were recorded by the iKEY M3 are named according
to the format of the file and are numbered according to the sequence in which
they were recorded. For instance, iKEY_001.MP3, iKEY_001.WAV, iKEY_002.
MP3, iKEY_002.WAV).
Transferring Files Between the RM3
and your Computer
Files recorded on the SD card can easily be transferred between the RM3 and
your computer using the included USB cable (24). First, ensure your unit is
powered off.
Connect the small end of the USB cable to the USB TO PC (23)
slot on the RM3 unit, and connect the other end to the USB port
on the back of your computer.
*Note: For best results, connect the USB cable to the back of your computer
and do not use a hub.
Conexiones y Control de sistema • Connexions & Utilisation • Anschlüsse und Systemeinstellungen
Connections and System Control
10
