Heating connection at
pump water use
The air curtain system that works with pump water is equipped with a heat exchanger. The
supply and return are indicated on the air curtain system and are located at the top left of the
appliance as standard.
Consult the technical data for the corresponding internal thread. The drain valve is located at the
bottom (at the collector) of the heat exchanger. For a smooth disassembly of the installation, 2
valves supplied by the client (for supply and return) must be fitted. In addition, a breather valve
must be fitted at the highest point of the heating pipe.
When using a solenoid valve and / or a discharge temperature controller, a dirt filter
supplied by the customer must be installed.
In some cases it must be checked whether a secondary pump is needed to improve the supply to
the air curtain installation.

Ceiling mounting*

When mounting on the ceiling, use the above-mentioned suspension points.
The number of suspension points depends on the type and length of the device.
Easyair
Confirmation points
4
6
8
1 1,5
m m
S S
M M
L L
LXX LXX
Standard model
2
m
S
M
L
LXX
2,5 3
m m
S S
M M
L L
LXX LXX
