for the whole shape of the hinge.
Once the recess for the first hinge has been obtained, stop
the machine. Loosen crank handles F (Fig. 9), slide the
machine to the approximate position for the next hinge
and once again secure crank handles F.
FITTING THE DISTRIBUTOR TUBE
Slightly loosen upper crank handle FS (Fig. 11) and sepa-
rate the machine from the frame rebate on this side by
approximately 0.5 cm to facilitate the fitting of previously
prepared distributor tube K (Fig. 11).
Fit distributor tube K (Fig. 11) to support H (Fig. 11 and 5).
To do this, pull pin G1 (Fig. 5) until connector I (Fig. 5) of
distributor tube K (Fig. 11) can enter between supports H
(Fig. 11 and 5). Release it when drill coincides with pin G1
(Fig. 5) to obtain the locking.
ROUTING THE SECOND AND THIRD RECESSES
To position the machine for the second recess, loosen both
crank handles F (Fig. 11), place centring device M (Fig. 11)
of hinge distributor tube K (Fig. 11) on the bottom part
of the recess of the first hinge and, leaning the machine
against the rebate, secure crank handles F (Fig. 11) once
again in this position.
Rout the second hinge recess in the same way as explained
for the first. This process is repeated to rout the third recess,
positioning distributor tube K (Fig. 11) over the second hinge.
This operation is repeated for the fourth if working with
distributor tube 4 (Fig. 2) for four hinges.
7.2 PLACING THE HINGES ON THE DOOR
FITTING THE DISTRIBUTOR TUBE
Fit hinge distribution tube K (Fig. 13) with stop reference
J (Fig. 13) facing downwards, into support G (Fig. 13) on
the side of the support marked "PUERTA DERECHA" (RIGHT
HAND DOOR) MI (Fig. 13). Secure it with pin G1 (Fig. 13).
MACHINE POSITION FOR THE FIRST RECESS
Loosen levers S (Fig. 13) and position the machine on the
edge of the door, with tube K (Fig. 13) towards the upper
side of it.
Move the machine along the edge of the door up to stop J
(Fig. 13) touches the extreme upper part of it, and tighten
the clamp vises to the door using crank handles F (Fig. 13).
Move base 2 of the machine (Fig. 12 and 13) up to stops
Y (Fig. 12), situated on either side of the base, touch the
heads of screws Z (Fig. 12). Secure levers S (Fig. 13) once
again in this position.
The position of screws Z (Fig. 12) with respect to stops Y (Fig.
12) provide a 1.5 mm space in the hung door between the
entrance face of the door and the interior side of the rebate.
If less space is required, screws Z can be supplemented with
washers of the required thickness.
ROUTING THE FIRST RECESS
Connect the machine to the mains. Push safety button X
(Fig. 8), and press the switch to start the machine.
By gradually pushing motor body 1 (Fig. 13), the cutter
bit will make an incision on the rebate to the depth of the
10
previously adjusted hinge. Secure the machine at this depth
with knob U (Fig. 13).
Next, move the motor body lengthways and sideways,
following the outline of the template to obtain a recess
for the whole shape of the hinge.
Once the recess for the first hinge has been obtained, stop
the machine and loosen knob U (Fig.13).
CHANGING THE DISTRIBUTOR TUBE
Remove distributor tube K (Fig. 13) from support G (Fig.
13) and fit it again to the same support. However this time
place stop J (Fig. 13 and 14) facing upwards.
ROUTING THE SECOND AND THIRD RECESSES
Loosen both crank handles F (Fig. 13), releasing the pressure
on the door thickness, and slide the machine to the position
of the second hinge.
The distance between hinges (Fig. 14) is obtained by po-
sitioning centering device M (Fig. 14) of hinge distributor
tube K (Fig. 14) over the lower part of the recess of the
first hinge. This leaves the machine at the exact distance
required for carrying out the recess for the second hinge.
Secure the ensemble to the door with crank handles F (Fig.
14) in the same way as the first hinge, and rout the recess.
This process is repeated to rout the third recess, positioning
distributor tube K (Fig. 14) over the second hinge. The
operation is repeated for the fourth if working with tube
4 (Fig. 2) for 4 hinges.
8. PLACING HINGES WITH TEMPLATES ON LEFT-HAND
DOORS
Ensure that the template and the distributor tube have
been correctly set up for working on left-hand doors, as
explained in section 6, PREPARING THE ROUTER
8.1 PLACING THE HINGES ON THE FRAME
The process to follow for routing the recesses is the same as
that for the frames for right-hand doors, the only difference
being that support G (Fig. 5) must be used-marked MARCO
IZQUIERDO (LEFT-HAND FRAME)-as a reference for locating
the first hinge in the frame and for mounting distributor
tube K in it. This is also used for successive ones (Fig. 5).
8.2 PLACING THE HINGES IN THE DOOR
The process to follow for milling the recesses is the same as
that for the frames for right-opening doors, the only diffe-
rence being that support H (Fig. 5) must be used- marked
MARCO IZQUIERDO (LEFT-HAND FRAME)-for mounting
distributor tube K, used for placing the recesses (Fig. 5).
9. PLACING AN ADDITIONAL HINGE ADJACENT
TO THE FIRST ONE
In order to fit an additional hinge in place at a distance
between centres of 225 mm, remove the hinge distributor
tube 3 or 4 (Fig. 2) from the machine and mount the addi-
tional hinge position stop 10 (Fig. 2) on the hinge distributor
connector 5 (Fig. 2), on the side opposite from stop J (Fig. 2).
After positioning stop J on the lower part of the recess of
