Avtech Push Video AVN801 Serie Manuel Utilisateur page 9

Function Icon
Live
DPTZ*
Backup
Config.
Media Type
Quality
Video Resolution
Live View Size:
Normal Size*
Fit to screen*
Scale*
CIF Resize
Snapshot
Full Screen
DPTZ*
Audio On / Off
Manual Alarm Out
* AVN801 Only
User Level
Supervisor / Power User
/ Normal User / Guest
Supervisor / Power User
/ Normal User
Supervisor / Power User
Supervisor
-- Supervisor / Power User
/ Normal User / Guest
Supervisor / Power User
--
/ Normal User
-- Supervisor / Power User
/ Normal User
Supervisor / Power User
/ Normal User
Supervisor / Power User
/ Normal User
Supervisor / Power User
/ Normal User
Supervisor / Power User
/ Normal User
Supervisor / Power User
/
/ Normal User
Supervisor / Power User
/ Normal User
Description
Switch to the live view page.
Switch to the DPTZ configuration page.
For details, please refer to "2.3 Digital PTZ (DPTZ) Operations" at page 5.
Enter the event record list for video playback.
For details, please refer to "2.4 Event Record Search & Playback' at page 5.
Switch to the system configuration page, and the functions available for
"Supervisor" and "Power User" are different.
For details, please refer to "3.1 System configuration menu" at page 7.
Select the image player from the drop-down list:
 H.264 / MPEG-4 / Motion JPEG
 QuickTime
QuickTime is Apple Inc.'s multimedia software. You need to have QuickTime
installed in your operating system before selecting "QuickTime". When it is
selected, you will be promoted to enter the user name and password to access
the camera.
VLC

Click & drag the slider to select the video quality:
Basic / Normal / High / Best.
Select the image resolution from the drop list:
AVN801
 SXGA (1280 x 1024)
 HD720P (1280 x 720)
 VGA (640 x 480)
 QVGA (320 x 240)
The current live view size is the same as the selected resolution.
The selected resolution is resized to fit into the current live view size.
This icon doesn't work when the selected resolution is VGA or QVGA.
Click and hold the movable square on the left bottom corner of the live view
to move
This icon appears only when the selected resolution is larger than the current live
view size.
The QVGA resolution is resized to fit into the current live view size.
This icon appears only when the selected resolution is QVGA (320 x 240) or CIF
(352 x 240).
Click to take a snapshot of the current view on a new window. Right click
on the picture and re-save it to the location you want.
Click to display the image in full screen.
To exit the full screen mode, press "Esc" on your keyboard.
Click to enable digital PTZ functions.
Click to switch the audio-in on / off.
Click to force the connected alarm-out device to work. For example, when
your alarm device is a buzzer, click this button and your buzzer will start to
sound even if there's no alarm event.
4
AVN701
 D1 (720 x 480)
 CIF (352 x 240)
