Reset(1)

1.4 Cabling

Plug in one end of the network cable to the WAN port of the Wireless Internet
Broadband Router.
Plug in the other end of the network cable to the Ethernet port of the xDSL or Cable
modem (E.G A02-RA141 or A02-RA111).
Use another network cable to connect to the Ethernet card on the computer system;
the other end of the cable connects to the LAN port of the Internet Broadband
Router. Since the Wireless Broadband Router has four ports, you can connect up to
four computers directly to the unit. There you do not have to buy a switch to
connect these computers since one Internet Broadband Router functions both as a
connection-sharing unit and as a switch.
The control LEDs of the Wireless Internet Broadband Router are clearly visible and
the status of the network link can be seen instantly:
1. With the power source on, once the device is connected to the broadband
modem, the Power, LAN, WLAN and WAN port link LEDs of the Internet
Broadband Router will light up indicating a normal status. Led Status blinks.
2. While the WAN is link up to the ADSL/Cable modem, the WAN port's Link/ACT
LED will light up.
3. While the LAN is link up to the computer system, the LAN port's Link/ACT LED
will light up.
After the device has turned on, press it to reset the
device or restore to factory default settings. Use a pin-
shape item to push to reset this device to factory default
settings. It will be useful too when the manager forgot the
password to login, but the setting will be back to default
setting.
