RM50000 SERIES
(
RANGE HOOD
A combination of Italian chimney hood design with
tremendous value to meet the requirements of
today's conventional appliance and kitchen styles.
FEATURES
•
Professional style design
•
Finishes: 430 Stainless Steel #4 Brushed, White, Black
•
Wall mount installation
•
Seamless corners for easy cleaning
•
Ducted/non-ducted telescopic flue - fits 8 ft. to 9 ft. ceilings
•
6" round duct connector/backdraft damper
•
Includes non-ducted kit for indoor exhaust recirculation
•
270 cfm centrifugal blower
•
Multi-speed slide control
•
Dual incandescent lighting (2 x 40 W) (bulbs included)
•
Dishwasher-safe aluminum filter features a quick-release
latch and professional style appearance
•
Available sizes: 30" , 35-7/16"
OPTIONS
•
Replacement grease filter and bulbs available
•
Replacement charcoal filters available (Model FILTEREB40
or Part No. SB03300495)
•
Flue Extension for 10-ft. ceiling (ducted applications) (Model
RFX50 series in Stainless Steel, White and Black — 35"
long)
•
Flue Extension for 10-ft. ceiling (non-ducted applications)
(Model RFXN5004 in Stainless Steel only — 35" long)
SPECIFICATIONS
VOLTS AMPS CFM
120 2.86 270
REFERENCE QTY.
)
SONES DUCT
6.5 6" round
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Range hood shall be Broan Model RM50000.
Unit shall be for indoor use only.
Unit shall be convertible between ducted (using a washable
aluminum filter) and non-ducted (using a recirculation kit).
Motor to be permanently lubricated.
Unit shall have four-speed fan switch and separate light switch.
Sides shall be mitered and bottom edge hemmed - with no
sharp edges.
Air delivery shall be no less than 270 CFM.
Unit shall be U.L. and cUL listed.
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed
by the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product
performance is rated at 0.1 in. static pressure, based
on tests conducted in a state-of-the-art test laboratory.
Sones are a measure of humanly-perceived loudness,
based on laboratory measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
90H
Date
99043162E
