1.7

TECHNICAL DETAILS

See also the type plate.
Model
Serial no.
Pressure relief valve
Length of stroke
Net stroke
Stroke lateral movement
Pressure switch blocking
Power blocking
Pressure switch releasing
Power releasing
Electrical capacity
Mains connection
Mains fusing
Control voltage
Potential free contact
Time needed for locking
Setup
Total length
Length needed in front of dock
Height
Noise level
Combilok
from 184500
230 Bar
3250 mm
2800 mm
400 mm
50 Bar
14 kN(=1400 kg.)
210 Bar
15.5 kN (=1550 kg.)
2.2 kW
3 x 400V, 50 Hz, 1 x nil,1 x earth
3 x 230V, 1 x earth
3 x 16 A
24 V=
max. 150 V=, 30 W
of 125 V~, 60 VA
30 sec.
Outside (hydro-unit and control box inside)
7500 mm
ca. 8500 mm
350 mm
74 dB(A)
