5-1 Resistances
Ω Ω Ω Ω Ω 400 Ω
4 kΩ
Digital
0.1 Ω 1 Ω
resolution
Bargraph 10 Ω 100 Ω
resolution
± 1 % rdg
Accuracy
± 4 counts
Voltage
on
Protection
5-2 Continuity sound test
On the 400 Ω range, emission of a continuous beep for a resistance
R - 40 Ω. Response time: 100 ms

6 - DIODE TEST

Never make a diode test on a live circuit
Connect the leads to the multimeter and to the terminals of the
component to be tested.
Place the selector switch on the
- in forward direction the display gives the value of the junction in
volts (resolution 1 mV)
- accuracy: ± 1% rdg ± 2 counts
- open circuit voltage: 3.2 V typical
- short circuit current: 0.6 mA
- in reverse direction the display indicates the open circuit
voltage, around 4 V.
Memorise the value, if necessary, by pressing the HOLD button.
With this function, it is possible to test, besides classic diodes,
LED's or any other semiconductor in which the junction
corresponds to a direct voltage less than 3 V.
Protection: idem Resistances
40 kΩ 400 kΩ 4 MΩ
10 Ω 100 Ω
1 kΩ
1 kΩ 10 kΩ 100 kΩ
± 1 % rdg
± 0.5% rdg ± 3 counts
± 4 counts
≤ 0.4 V DC
500 V rms and 750 V peak
function:
40 MΩ
10 kΩ
1 MΩ
± 1.5 % rdg
± 4 counts
