OPERATING INSTRUCTIONS

CONTROL PANEL

1. Power Button: Press and hold this button for 3
seconds to turn the appliance on or off.
2. Light Button: Press this button to set the interior
light to be on continuously. Press again to set the
light to be controlled by the actuator switch.
3. Power Light: Indicator light illuminates to signify
that the cooling mode is currently in operation.
4. Upper Chamber Display: Display screen shows
current cabinet temperature and set temperature
of the upper zone.
5. Lower Chamber Display: Display screen shows
current cabinet temperature and set temperature
of lower zone.
6. °C/°F: Adjacent indicator light denotes which
scale of temperature is displayed.
7. Set Upper Button: Used to set the temperature in
the upper zone.
8. Set Lower Button: Used to set the temperature in
the lower zone.
3
1
4
2

INTERIOR LIGHT

The interior light will default to turning on and off
when the door is opened or closed.
• Press the light button once to turn the light
permanently on.
• Press the light button again to turn the light
permanently off.
• Press the light button a third time to return to
default functioning.
This function is controlled by the actuator at the
bottom of the door pressing the switch on the
appliance. If this function is not working correctly,
check the position of the actuator.
6
7
°
°
5 °
°
8

FUNCTION INSTRUCTION

The default temperature setting is 12°C (54°F). The
default temperature scale is °F.
To switch the display between °F and °C, press
the Up and Down buttons simultaneously for
approximately 3-5 seconds.
The temperature can be set as low as 5°C (41°F) or
as high as 18°C (64°F).
Actual temperature inside the appliance can vary
based on ambient temperature, how often the
door is opened and how many warm bottles have
recently been added to the appliance.
Each depression of the Up and Down buttons will
adjust the temperature in 1° increments.
Door Ajar Alarm: If the door is not closed
completely for 5 minutes, an alarm will sound. Close
the door to silence the alarm.
If the door is closed and the alarm continues to
sound, check that the actuator at the bottom of
the door is making contact with the switch on the
appliance.
Temperature Memory: If the appliance loses power,
the control panel will remember the set temperature.
Once power is restored, the appliance will return to
normal functioning automatically.
Temperature Alarm: If the inner cabinet temperature
is higher than 23°C (73°F) for one hour, the error
code "HI" will show on the display panel and an
alarm will sound.
If the inner cabinet temperature is lower than 0°C
(32°F) for one hour, the error code "LO" will show
on the display panel and an alarm will sound.
If the inner cabinet temperature remains at 0°C
(32°F) for more than 30 minutes, the error code
"CL" will show on the display panel and an alarm
will sound. The appliance will stop functioning to
prevent the contents from freezing.
