GB

PARTS DESCRIPTION

Fig. 1 keypad
1. keys
2. red LED
3. voltage selector
4. terminal box
1-2 Power supply
3 Communication line (A)
4 Communication line (B)
Fig. 2 receiver
1. terminal box
1-2 relay output 1
3-4 relay output 2
5 Communication line (A)
6 Communication line (B)
7-8 Power supply
2. P1 button
3. L1 LED
4. P2 button
5. memory
6. voltage selector
Fig. 3 keypad opening
☼
47
